SERIES 7600
Butterfy Valve
The versatile Series 7600 Grooved-End Butterfy Valve has
features that can satisfy a wide range of service requirements
and allow it to be used with diverse fuids. Its ductile iron body
is epoxy coated to resist atmospheric attack, and the elastomer
encapsulated disc can be ordered with EPDM or nitrile materials.
Rugged enough to take the punishment, yet the Series 7600
Valve is light in weight for easy handling and installation.
The Series 7600 Valve is rated 200 PSI (13.8 bar) to full vacuum,
at temperatures from 0° to 150° F (-17.8° to 65.6° C). Every valve
is seat tested to 110% of rated pressure.
GENERAL SPECIFICATIONS
MATERIAL SPECIFICATIONS
BODY:
One-piece ductile iron, fully epoxy coated – light weight for
easy handling.
DISC:
Streamlined profle for maximum fow and minimal seat wear. The
ductile iron disc is available with a choice of EPDM or Nitrile
coverings.
STEM/DISC ATTACHMENT:
A splined interference ft creates a
permanent rigid connection between the disc and stem, and
eliminates the need for pins or bolts in the fow way.
STEM:
Two-piece design for maximum fow. Top stem is Double D,
giving positive indication of disc position at all times.
STEM SEAL:
The interference between the rubber covered disc hub and
the smooth, epoxy coated body provides the primary stem seal.
O-rings on both upper and lower stems provide a secondary seal.
HANDLE:
Two position on/off handle is standard.
TESTING AND CONFORMANCE:
Testing to MSS SP-67. Grooved ends
conform to the requirements of AWWA C606 for steel pipe.
1. BODY:
Epoxy Coated, ASTM A 536
2. DISC:
EPDM or NBR, ASTM A 536
3. LOWER STEM:
AISI 410
4. UPPER STEM:
AISI 410
5. STEM O-RING:
NBR
6. LATCH PLATE:
Zinc Plated, ASTM A 228
7. LATCH SPRING:
Electrolytic Coloring, ASTM A 228
8. NUT, SELF LOCKING:
ASTM A 563
9. HANDLE:
Zinc Plated, ASTM A 619
SERIES 7600 BUTTERFLY VALVE DIMENSIONS
Size
DIMENSIONS
A
B
C
D
E
F
G
H
K
L
In./mm
In./mm
In./mm
In./mm
In./mm
In./mm
In./mm
In./mm
In./mm
In./mm
In./mm
2
2
3
/
8
2
1
/
4
3
7
/
16
5
/
8
5
/
16
6
1
1
13
/
16
2
3
3
/
16
50
60.3
57.2
87.4
15.9
8.7
152.4
25.4
46.0
50.8
81.0
2
1
/
2
2
15
/
16
2
3
/
4
3
13
/
16
5
/
8
3
/
8
6
1
2
1
/
16
2
7
/
16
3
5
/
8
65
74.2
70.2
96.8
15.9
8.9
152.4
25.4
52.3
62.0
91.9
3
3
9
/
16
3
3
/
8
3
13
/
16
5
/
8
3
/
8
8
7
/
16
1
2
5
/
8
2
11
/
16
4
1
/
4
80
90.3
86.4
96.8
15.9
8.9
214.4
25.4
66.5
68.1
108.0
4
4
9
/
16
4
3
/
8
4
5
/
8
5
/
8
3
/
8
8
7
/
16
1
3
5
/
16
3
5
/
16
4
15
/
16
100
116.1
111.8
117.3
15.9
8.9
214.4
25.4
84.1
84.1
125.5
6
6
3
/
4
6
9
/
16
5
1
/
4
5
/
8
3
/
8
12
1
/
4
1
1
/
4
4
3
/
8
4
3
/
8
7
150
171.0
166.6
133.4
15.9
8.9
311.2
31.8
111.3
111.3
177.8
9
7
6
3
5
1
2
5
4
8
ORANGE GRIP
K REF.
H REF.
L
G REF.
F REF.
C
E D
A B
BLACK COATING
