Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
Hose Mender, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-HM90-0606 54355-0606 5/16 7.90
.59
15
.59
15
GC-HM90-0808 54355-0808 13/32 10.30
.79
20
.79
20
GC-HM90-1010 54355-1010 1/2 12.70
.98
25
.98
25
GC-HM90-1212 54355-1212 5/8 15.90
1.18
30
1.18
30
Hose Mender, 180 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-HM180-0606 54360-0606 5/16 7.90
1.97
50
2.13
54
GC-HM180-0808 54360-0808 13/32 10.30
2.36
60
2.13
54
GC-HM180-1010 54360-1010 1/2 12.70
2.76
70
2.48
63
GC-HM180-1212 54360-1212 5/8 15.90
3.15
80
3.15
80
Hose Mender, R12 Valve
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-HM12V-0606 54365-0606 5/16 7.90
1.46
37
1/4
6.35
GC-HM12V-0808 54365-0808 13/32 10.30
1.46
37
1/4
6.35
GC-HM12V-1010 54365-1010 1/2 12.70
1.46
37
1/4
6.35
GC-HM12V-1212 54365-1212 5/8 15.90
1.46
37
1/4
6.35
Hose Mender, R134a Valve
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-HM134V-0606 54370-0606 5/16 7.90
1.46
37
0.63
16
GC-HM134V-0808 54370-0808 13/32 10.30
1.46
37
0.63
16
GC-HM134V-1010 54370-1010 1/2 12.70
1.46
37
0.51
13
GC-HM134V-1212 54370-1212 5/8 15.90
1.46
37
0.51
13
Hose Mender, with Sight Glass
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-HMSG-0606 54375-0606 5/16 7.90
1.77
45
Same as GC-HM with sight glass
Same as GC-HM134V
except with R12 Valve
Picture Not Available
– 20 –
COOL CLIP
™
FITTINGS
For use with GALAXY
®
G4890 Hose
