Ford Spring Lock, Male
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FSLM-0606A 54330-0606A 5/16 7.90 FSL-06
2.36
60
GC-FSLM-0608A 54330-0608A 5/16 7.90 FSL-08
2.36
60
GC-FSLM-0808A 54330-0808A 13/32 10.30 FSL-08
2.36
60
GC-FSLM-1010A 54330-1010A 1/2 12.70 FSL-10
2.64
67
GC-FSLM-1210A 54330-1210A 5/8 15.90 FSL-10
2.64
67
GC-FSLM-1212A 54330-1212A 5/8 15.90 FSL-12
2.76
70
Ford Spring Lock, Male, 45 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE #
PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FSLM45-0606A 54333-0606A 5/16 7.90 FSL-06 1.30
33
1.50
38
GC-FSLM45-0608A 54333-0608A 5/16 7.90 FSL-08 1.30
33
1.50
38
GC-FSLM45-0808A 54333-0808A 13/32 10.30 FSL-08 1.26
32
0.94
24
GC-FSLM45-1010A 54333-1010A 1/2 12.70 FSL-10 1.42
36
1.26
32
GC-FSLM45-1210A 54333-1210A 5/8 15.90 FSL-10 1.42
36
1.26
32
GC-FSLM45-1212A 54333-1212A 5/8 15.90 FSL-12 1.42
36
1.26
32
Ford Spring Lock, Male, 90 Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE #
PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FSLM90-0606A 54335-0606A 5/16 7.90 FSL-06 2.13
54
1.61
41
GC-FSLM90-0608A 54335-0608A 5/16 7.90 FSL-08 2.13
54
1.61
41
GC-FSLM90-0808A 54335-0808A 13/32 10.30 FSL-08 2.44
62
1.73
44
GC-FSLM90-1010A 54335-1010A 1/2 12.70 FSL-10 2.52
64
2.01
51
GC-FSLM90-1210A 54335-1210A 5/8 15.90 FSL-10 2.52
64
2.01
51
GC-FSLM90-1212A 54335-1212A 5/8 15.90 FSL-12 2.52
64
2.01
51
Hose Mender
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-HM-0606
54350-0606 5/16 7.90
1.46
37
GC-HM-0608
54350-0608 5/16 7.90
1.46
37
GC-HM-0808
54350-0808 13/32 10.30
1.46
37
GC-HM-0810
54350-0810 13/32 10.30
1.46
37
GC-HM-1010
54350-1010 1/2 12.70
1.46
37
GC-HM-1210
54350-1210 5/8 15.90
1.46
37
GC-HM-1212
54350-1212 5/8 15.90
1.46
37
Picture Not Available
Picture Not Available
Picture Not Available
One Source, One System, One Solution.
www.hydraulics.goodyear.com
Information in this catalog supersedes all previously printed material and is current as of April 2006. Due to continual product improvements, Goodyear reserves the right to alter specs without prior notice.
For the most current product information, visit us online.
– 19 –
COOL CLIP
™
FITTINGS
For use with GALAXY
®
G4890 Hose
