Compressor O-Ring Tube, Female, R134a Valve, 90 Block
Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE #
PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-COTF134V90B-0810 54145-0810 13/32 10.30 1-14
.91
23
1.97
50
.63
16
GC-COTF134V90B-1010 54145-1010 1/2 12.70 1-14
.91
23
1.97
50
.51
13
GC-COTF134V90B-1210 54145-1210 5/8 15.90 1-14
.91
23
1.97
50
.51
13
Flareless Tube, Braze-On
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FTBO-0606
54210-0606 5/16 7.90 3/8 Fitting
1.46
37
GC-FTBO-0808
54210-0808 13/32 10.30 1/2 Fitting
1.46
37
GC-FTBO-1010
54210-1010 1/2 12.70 5/8 Fitting
1.46
37
GC-FTBO-1210
54210-1210 5/8 15.90 5/8 Fitting
1.46
37
GC-FTBO-1212
54210-1212 5/8 15.90 3/4 Fitting
1.46
37
Flareless Tube, Male
HOSE ID
THREAD DROPLENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FTM-0606
54230-0606 5/16 7.90 5/8-18
2.44
62
GC-FTM-0608
54230-0608 5/16 7.90 3/4-16
2.44
62
GC-FTM-0806
54230-0806 13/32 10.30 5/8-18
2.44
62
GC-FTM-0808
54230-0808 13/32 10.30 3/4-16
2.56
65
GC-FTM-0810
54230-0810 13/32 10.30 7/8-14
2.56
65
GC-FTM-1008
54230-1008 1/2 12.70 3/4-16
2.80
71
GC-FTM-1010
54230-1010 1/2 12.70 7/8-14
2.80
71
GC-FTM-1210
54230-1210 5/8 15.90 7/8-14
3.31
84
GC-FTM-1212
54230-1212 5/8 15.90 1 1/16-14
3.31
84
Flareless Tube, Male, 90 Block Elbow
HOSE ID THREAD
DROP
LENGTH
VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-FTM90B-0606 54235-0606 5/16 7.90 5/8-18 1.22
31
1.06
27
GC-FTM90B-0608 54235-0608 5/16 7.90 3/4-16 1.22
31
1.06
27
GC-FTM90B-0806 54235-0806 13/32 10.30 5/8-18 1.22
31
1.06
27
GC-FTM90B-0808 54235-0808 13/32 10.30 3/4-16 1.73
44
1.26
32
GC-FTM90B-0810 54235-0810 13/32 10.30 7/8-14 1.73
44
1.26
32
GC-FTM90B-1008 54235-1008 1/2 12.70 3/4-16 1.73
44
1.26
32
GC-FTM90B-1010 54235-1010 1/2 12.70 7/8-14 2.09
53
1.57
40
GC-FTM90B-1210 54235-1210 5/8 15.90 7/8-14 2.52
64
2.28
58
GC-FTM90B-1212 54235-1212 5/8 15.90 1 1/16-14 2.52
64
2.28
58
Picture Not Available
Picture Not Available
