Compressor Pad Block, R12 Valve/Switch, 90 Block Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-CB12VS90-0808 54110-0808 13/32 10.30
GC-CB12VS90-1008 54110-1008 1/2 12.70
GC-CB12VS90-1208 54110-1208 5/8 15.90
Compressor Pad Block, R12 Valve/Switch Reversed, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-CB12VSR90-0808 54112-0808 13/32 10.30
GC-CB12VSR90-1008 54112-1008 1/2 12.70
GC-CB12VSR90-1208 54112-1208 5/8 15.90
Compressor O-Ring Tube, Female, 45 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-COTF45-0810 54133-0810 13/32 10.30 1-14 0.39 10 1.65 42
GC-COTF45-1010 54133-1010 1/2 12.70 1-14 0.39 10 1.65 42
GC-COTF45-1210 54133-1210 5/8 15.90 1-14 0.39 10 1.65 42
Compressor O-Ring Tube, Female, 90 Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
Similar to GC-COTF90B GC-COTF90-0810 54135-0810 13/32 10.30 1-14 0.91 23 1.77 45
except bent tube, not block GC-COTF90-1010 54135-1010 1/2 12.70 1-14 0.91 23 1.77 45
GC-COTF90-1210 54135-1210 5/8 15.90 1-14 0.91 23 1.77 45
Compressor O-Ring Tube, Female, 90 Block Elbow
HOSE ID THREAD DROP LENGTH VALVE
DESCRIPTIVE # PRODUCT # INCH MM SIZE INCH MM INCH MM INCH MM
GC-COTF90B-0810 54137-0810 13/32 10.30 1-14 0.91 23 1.97 50
GC-COTF90B-1010 54137-1010 1/2 12.70 1-14 0.91 23 1.97 50
GC-COTF90B-1210 54137-1210 5/8 15.90 1-14 0.91 23 1.97 50
Picture Not Available
Picture Not Available
– 16 –
COOL CLIP ™ FITTINGS
For use with GALAXY® G4890 Hose
