7
SPECIAL GASKETS
Gaskets of special design can be
engineered and fabricated using
the same basic fundamentals of
Flexitallic Spiral Wound Gasket
design and construction to cover
a wide range of applications in
installations for which there are
no industry-wide standards.
Special gaskets have been
designed for valves, pumps,
compressors, turbines, boilers,
heat exchangers, etc. Consult with
Flexitallic engineers as early in the
design stage as possible.
GOVERNMENT SPECIFICATIONS
Flexitallic Spiral Wound Gaskets
are available in accordance with
Military Specifications
MIL-G-24716, and MIL-G-15342,
latest revisions. When making
an inquiry, refer to the proper
Government Specification
number.
DIMENSIONAL DATA - STYLE CG & CGI GASKETS
TO SUIT STANDARD RAISED FACE AND FLAT FACE FLANGES
All CG and CGI Gaskets for these standard flanges are 4.5mm (O.175in) thick, fitted with 3.2mm
(0.125in) thick solid metal rings. Unless otherwise stated.
Flexitallic style CG and CGI Spiral wound gaskets can be ASME B16.5
manufactured in accordance with all relevant gasket BS 1560
standards to suit the following flange designations. BS 10
ASME B16.47 SERIES B (API 605)
Please note that gaskets for non-standard flanges ASME B16.47 SERIES A (MSS SP 44)
are also readily available. BS 4504
DIN FLANGES
WHEN ORDERING PLEASE SPECIFY EXAMPLE
GASKET STYLE FLEXITALLIC STYLE “CGI” SPIRAL WOUND
GASKET
NOMINAL PIPE SIZE (NPS) 4”
PRESSURE RATING CLASS 900
GASKET STANDARD ASME B16.20
WINDING MATERIALS 316L/FLEXICARB
OUTER RING MATERIAL CARBON STEEL
INNER RING MATERIAL 316L
Please select correct gasket style for your particular application. See page 6 “Gasket Selection”.
*Style CG *Style CGI
