CODE NO. DURAMAX® BASE WIDTH HEIGHT WALL THICKNESS WT./FT. LENGTH
PART NO. (W) (H) (WT) UP TO
DB-50 802005001 2 1/8” 2” 7/16” 1.2 LBS. 60 FT.
DB-75 802007501 3 1/8” 2 7/8” 11/16” 2.6 LBS. 60 FT.
DB-100 802009001 4 1/4” 3 7/8” 3/4” 5.1 LBS. 60 FT.
Reaction load, deflection and energy absorption data can be found on next page.
100 SERIES
H
W
WT
TAPERED D-SHAPE / KEY BORE
The Duramax® Tapered D-shaped, Key-bore is designed for marine
and industrial applications. Provides protection for small vessels,
docks, loading docks, trucks and other equipment. Offered in three
EPDM colors: black, non-marking grey, and white. Also see our 90
degree molded corner guard/end caps and poly washer strips.
90° Molded Insert Corners / End Caps
Insert the legs of these molded EPDM corners into the bore of the DB 50,
75 and 100 for a 90 degree corner. Or one side of the insert may be cut
off and used to mount flush to vessel or
structure and cap off the end of the
extrusion. Stocked in black, grey and white.
CODE NO. DURAMAX® COLOR
PART NO.
DB-51 802005101 BLACK
DB-52 802005202 GREY
DB-53 802005303 WHITE
DB-76 802007601 BLACK
DB-77 802007702 GREY
DB-78 802007803 WHITE
DB-103 802009301 BLACK
DB-104 802009402 GREY
DB-105 802009503 WHITE
100 Series Poly Washer Strip
Supplied in 10-foot sections, our tough
polycarbonate washer strip slides
inside the Key-bore for mounting.
CODE NO. DURAMAX® WIDTH THICKNESS LENGTH
PART NO.
DB-50NS 802000025 1” 3/8” 10 FT.
DB-75NS 802000026 1 1/4” 3/8” 10 FT.
DB-100NS 802000027 1 3/4” 3/8” 10 FT.
Thickness
W
9
12"
Wood Dock Ship’s Hull
12" 12"
2"
Poly Washer
Strip
D D-SHAPE / KEY BORE
D-SHAPE / KEY BOR
E D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE D-SHAPE / KEY BORE
www.DuramaxMarine.com
DB-50
DB-75
DB-100
