Spring Return (normally closed)
Double Acting
Size A B C D E Brass
Part # Price/E
1/4"
3/8"
1/2"
3/4"
1"
1¼"
1½"
2"
2½"
3"
4.72
4.72
4.72
4.81
6.28
6.50
6.99
8.45
8.90
8.90
2.80
2.80
2.80
2.80
3.74
3.74
3.74
4.69
4.69
4.69
2.64
2.64
2.87
3.19
3.74
4.39
4.86
5.73
6.93
7.08
5.49
5.49
5.49
5.49
7.45
7.45
7.45
9.10
9.10
9.10
1.32
1.32
1.44
1.60
1.87
2.20
2.43
2.87
3.47
3.54
BV3BV*R-0251BBC
BV3BV*R-0381BBC
BV3BV*R-0501BBC
BV3BV*R-0751BBC
BV3BV*R-1001BBC
BV3BV*R-1251BBC
BV3BV*R-1501BBC
BV3BV*R-2001BBC
BV3BV*R-2501BBC
BV3BV*R-3001BBC
$646.05
646.05
646.05
670.10
815.10
948.25
1176.75
1721.65
2519.95
2537.95
3-Way Brass Ball Valve
• pressure rating: 400 PSI WOG 100 PSI WSP
• maximum temperature: 344ºF
• blow-out proof stem
• chrome-plated brass ball
• PTFE seats with O-ring backing for low
operating torque
• PTFE seats and double O-ring stem packing
• 100% tested
• reduced port
• ISO 5211 mounting pad
Rack and Pinion Actuator
• bi-directional stops for ±5º travel adjustment
• 80 PSI plant air required
• maximum operating pressure: 120 PSI
• operating temperature range: -40ºF to 200ºF
• hard anodized aluminum body
• NAMUR mounting
• nickel plated anti-blowout pinion
• Buna-N O-rings
• visual position indication
• tested to one million cycles
Caution !
Even though there are torque safety factors built into our automated ball valve packages, actual service conditions
must also be considered when selecting the proper product for the appropriate application.
For example: Severe service conditions such as dirty water, dirty air, all slurries, raw sewage water, oils, and other viscous fluids can have a
dramatic affect in raising the torque requirements of ball valves as much as 75% and therefore larger actuators may be required.
Please consult the factory when dealing with these types of applications.
A wide variety of switches, solenoids, positioners, etc., are available.
Contact the factory at 800.789.1718 or visit bradfordfittings.com for details.
Refer to page 633 for alternate flow paths.
Default Flow Paths
position A
position D
T port
position A
position B
L port
* T = t-port style
* L = l-port style
Size A B C D E Brass
Part # Price/E
1/4"
3/8"
1/2"
3/4"
1"
1¼"
1½"
2"
2½"
3"
3.76
3.76
3.76
3.85
5.53
5.75
6.24
7.55
8.00
8.00
1.77
1.77
1.77
1.77
3.20
3.20
3.20
3.74
3.74
3.74
2.64
2.64
2.87
3.19
3.74
4.39
4.86
5.73
6.93
7.08
4.33
4.33
4.33
4.33
5.32
5.32
5.32
5.51
5.51
5.51
1.32
1.32
1.44
1.60
1.87
2.20
2.43
2.87
3.47
3.54
BV3BV*R-0251BCC
BV3BV*R-0381BCC
BV3BV*R-0501BCC
BV3BV*R-0751BCC
BV3BV*R-1001BCC
BV3BV*R-1251BCC
BV3BV*R-1501BCC
BV3BV*R-2001BCC
BV3BV*R-2501BCC
BV3BV*R-3001BCC
$504.40
504.40
504.40
528.45
643.70
776.90
1005.40
1449.20
2247.50
2265.50
Dimensions are approximate. Engineering dimensions are available upon request.
Specifications are subject to change without notice.
All dimensions are given in inches, unless noted. Dimensions
are approximate. Engineering dimensions are available upon
request. Specifications are subject to change without notice.
E
D
C
B
A
E C
D
A
B
