TEST CONES
Copyright © 2002-2007 65 BrakeQuip
BQ21 BQ206 BQ206H
BQ206HS
BQ206S BQ207
BQ208 BQ208H
BQ207H
SYSTEM AIDS
BQ23 BQ2001 BQ1021A
BQ2005 BQ2008 BQ2009
BQ2010 BQ37 BQ1014
Fitting Test Spade Constriction Gauge Rear Crimp Setting Tool
Pro System
Crimp Head Dust Cover
Pro System
Crimp Setting Tool
Pro System
Rear Crimp Setting Tool
Countersink Drill Bit Econo System
Crimp Setting Spade
Econo System
Crimp Setting Clip
PART NO. QUANTITY SIZE
BQ27 2 3/8"
BQ27H 2 3/8"
BQ28 2 10mm
BQ28H 2 10mm
BQ29 2 7/16"
BQ29H 2 7/16"
BQ30 2 12mm
BQ30H 2 12mm
BQ38 2 16mm
BQ38H 2 16mm
BQ39 2 15mm
BQ39H 2 15mm
BQ1020 1 3/8" - 5/8"
Pressure Test Adapter Kit
Assortment Kit
BQ7013
BQ21 Test Cone is designed
as an aid for testing banjo
fittings.
BQ206 and BQ206H are universal Test Cones for doing
most general applications.
BQ206S and BQ206HS Test
Cones are designed for
testing female swivel fittings
and female fittings with a
drill point seat (DPS).
BQ207 and BQ207H Test Cones are designed for testing
female fittings with inverted seats.
BQ208 and BQ208H Test Cone are designed for testing
extra long fittings
