MISCELLANEOUS HOSE FITTINGS
Copyright © 2002-2007
5
BrakeQuip
A = Asian EU = European US = United States UNI = Universal V = Various
HF09
3/8"NF 37° Double 3/16"
58mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
No. 3 JIC
HF10
3/8"NF 37° Double 3/16"
52mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel 45°
No. 3 JIC
HF11
3/8"NF 37° Double 3/16"
45mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel 90°
No. 3 JIC
HF12
7/16'NF 37° Double
1/4"
50mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
No. 4 JIC
HF13
7/16'NF 37° Double
1/4"
56mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel 45°
No. 4 JIC
HF14
7/16'NF 37° Double
1/4"
48mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel 90°
No. 4 JIC
HF61
5/16"NF 37° Double
35mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
No. 2 JIC
FEMALE SWIVEL
HF81
3/8"NF
Bubble
3/16"
76mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
HF82
M10x1
DIN
3/16"
71mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
HF89
7/16"NS Double
1/4"
120mm US
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
HF53
M10 x 1
DIN
3/16"
57mm US
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
HF54
3/8"NF Double
3/16"
125mm US
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
HF63
3/8"NF Double
3/16"
88mm V
THREAD FLARE TUBE SIZE
OAL
FITS
Swivel
MALE SWIV
EL
