IMPERIAL MALE FITTINGS
Copyright © 2002-2007 33 BrakeQuip
A = Asian EU = European US = United States UNI = Universal V = Various
HFIM15
3/8BSF 12.5mm 16mm 40mm EU
THREAD THREAD LENGTH HEX OAL FITS
HFIM16
7/16NF 13mm 17mm 61mm US
THREAD THREAD LENGTH HEX OAL FITS
HFIM01
3/8NF 12.5mm 16mm 40mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM01B
3/8NF 12.5mm 14mm 40mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM03
7/16NF 12mm 16mm 40mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM04
11/16NF 20mm 19mm 50mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM08
1/2NF 15.5mm 17mm 43mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM09
7/16NF 13.5mm 16mm 69mm US
THREAD THREAD LENGTH HEX OAL FITS
HFIM10
3/8NF 12.5mm 16mm 44mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM11
3/8NF 13mm 16mm 68mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM13
7/16NS 12mm 16mm 40mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM14
7/16NS 12mm 16mm 78mm US
THREAD THREAD LENGTH HEX OAL FITS
Brass
HFIM18
3/8NF 12mm 16mm 53mm US
THREAD THREAD LENGTH HEX OAL FITS
HFIM19
1/8NPT 12mm 14mm 40mm V
THREAD THREAD LENGTH HEX OAL FITS
HFIM21
3/8NF 12.5mm 16mm 53mm V
THREAD THREAD LENGTH HEX OAL FITS
STANDARD MOUNT
