BANJO FITTINGS
Copyright © 2002-2007
19
BrakeQuip
A = Asian EU = European US = United States UNI = Universal V = Various
HFB118
10mm 12mm 20mm 90°
50mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Right
HFB119
10mm 12mm 20mm 90°
60mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Right
HFB120
10mm 12mm 20mm 90°
60mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
HFB121
10mm 12.7mm 22.2mm 65°
127mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Right
HFB122
10mm 12.7mm 22.2mm 65°
127mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
HFB113
10mm 11.8mm 42mm 30°
130mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB114
10mm 11.8mm 42mm 30°
130mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB115
3/8"
1/2"
22.2mm 55°
112mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB95
7/16"
11.6mm 20mm 90°
110mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB102
3/8"
1/2"
23mm 23°
140mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB103
3/8"
1/2"
23mm 23°
140mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB107
10mm 11.6mm 20mm 75°
86mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB108
10mm 11.6mm 20mm 75°
86mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
Right
Left
Right
Left
Right
Left
Right
HFB116
3/8"
1/2"
22.2mm 55°
112mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
HFB117
10mm 12mm 20mm 90°
50mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
TUBE STYLE - LEFT/RIGHT
