Page 17 - FittingsCatalog

A = Asian EU = European US = United States UNI = Universal V = Various
HFB310
10mm 11.5mm 19mm 10° 82mm V
HOLE THICK WIDTH ANGLE OAL FITS
HFB309
10mm 11.5mm 17mm 15° 62mm V
HOLE THICK WIDTH ANGLE OAL FITS
HFB22
10mm 11.5mm 19mm – 172mm UNI
HOLE THICK WIDTH ANGLE OAL FITS
HFB23
7/16" 1/2" 19mm – 172mm UNI
HOLE THICK WIDTH ANGLE OAL FITS
HFB182
3/8" 1/2" 22.2mm 165mm US
HOLE THICK WIDTH ANGLE OAL FITS
HFB188
3/8" 12.5mm 40mm 90° 116mm US
HOLE THICK WIDTH ANGLE OAL FITS
HFB193
3/8" 1/2" 23mm 10° 110mm US
HOLE THICK WIDTH ANGLE OAL FITS
HFB203
3/8" 11mm 25mm 35° 75mm US
HOLE THICK WIDTH ANGLE OAL FITS
HFB379
12mm 8.5mm 19mm 30° 60mm EU
HOLE THICK WIDTH ANGLE OAL FITS
Copyright © 2002-2007 17 BrakeQuip
BANJO FITTINGS
TUBE S
TYLE - EITHER SIDE
UNIVERSAL
