BANJO FITTINGS
Copyright © 2002-2007
10
BrakeQuip
A = Asian EU = European US = United States UNI = Universal V = Various
HFB24
10mm 8mm 17mm 75°
64mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB29
10mm 10mm 28mm 40°
52mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB30
10mm 10mm 17mm 90°
52mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB31
10mm 10mm 17mm 25°
68mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB32
10mm 8mm 17mm 90°
39mm V
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB33
10mm 8mm 17mm 75°
60mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
Right
HFB75
10mm 10mm 17mm 90°
61mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
HFB92
10mm 10mm 18mm 55°
90mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
HFB93
10mm 10mm 18mm 55°
90mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
Right
HFB157
10mm 10mm 18mm 70°
102mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB158
7/16"
15mm 35mm 35°
57mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
HFB159
7/16"
15mm 35mm 35°
57mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Right
HFB164
10mm 8mm 17mm 75°
64mm A
HOLE
THICK WIDTH ANGLE OAL
FITS
Right
HFB105
3/8"
1/2"
21mm 25°
113mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
HFB106
3/8"
1/2"
21mm 25°
113mm US
HOLE
THICK WIDTH ANGLE OAL
FITS
Left
Right
ROUND STYLE - BENT
