BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
KRHCA0109
Compressed Air
T142AK - 600 PSI Oil Resistant Steel Braided
Reinforced Air Hose
APPLICATION
High pressure air for mines and quarries. Designed for long
lasting service and maximum safety in heavy duty applications
where resistance to oil is required.
COVER
Yellow SBR/NBR — abrasion, ozone, hydrocarbon and fame
resistant — pin pricked.
REINFORCEMENT
High tensile steel wire braids.
TUBE
Black NBR (RMA Class A) oil mist resistant.
TEMPERATURE RANGE
-40°F (-40°C) to 242°F (+120°C)
STANDARD LENGTHS
100 feet: 2" through 3"
50 feet: 2" and 3"
BRANDING
ALFAGOMMA – ITALY T142 HIGH TEMP STEEL AIR — OIL
RESISTANT Embossed.
COUPLING SUGGESTIONS
Steel or malleable iron male insert NPT, female ground joint or washer type with spud, or universal quick-acting couplings attached
with 2 or 4 bolt interlocking clamps or bands.
H
Kuriyama offers a full line of ground joint couplings and clamps and universal air hose couplings and clamps. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T142AK200
2
51
2.52
64
148
600
10
T142AK250
2 1/2
63
3.11
79
206
600
12 1/2
T142AK300
3
76
3.62
92
254
600
15
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MAX. REC.
MIN. BEND
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
WP (PSI)
RADIUS (in.)
*T133AK - 600 PSI High Temp Air Hose is Being Discontinued.
KRHCA 109
