BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
46 KRHCA0109
Material Handling
APPLICATION
Designed to convey abrasive sand and shot blast material.
COVER
Black or green, conductive SBR/NR blend – abrasion and
ozone resistant – pin pricked.
REINFORCEMENT
High tensile textile cords — 4-ply construction.
TUBE
Static conducting natural rubber, offering excellent abrasion
resistance.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
50 or 100 feet
WORKING PRESSURE
Constant Pressure — 10 Bar (150 PSI)
BRANDING
ALFAGOMMA – ITALY T750 – 10 BAR (150 PSI)
SANDBLAST Ω
T750AA / T750AG - 150 PSI 4-Ply Sandblast
Hose
NOTE: Tolerances according to RMA Class 311-A
T750AA/AG075 3/4 19 1.50 38 0.236 63
T750AA/AG100 1 25 1.89 48 0.283 97
T750AA/AG125 1 1/4 32 2.17 55 0.283 116
T750AA/AG150 1 1/2 38 2.36 60 0.260 132
T750AA200 2 51 2.87 73 0.260 167
Nominal Specifcations - T750AA/AG 4-Ply
SERIES NO. NOMINAL ID NOMINAL OD TUBE THICKNESS APPROX. WT.
(in.) (mm) (in.) (mm) lbs./100 ft.
COUPLING SUGGESTIONS
Sandblast couplings and nozzle holders attached with screws. See next column for coupling part numbers.
H Kuriyama offers a full line of sandblast couplings. Refer to current Kuriyama-Couplings™ and Accessories Catalog.
3/4 Q-1AL, Q-1BR, Q-1PI NH-1AL, NH-1BR – SBG
1 Q-2AL, Q-2BR, Q-2PI NH-2AL, NH-2BR – SBG
1 1/4 Q-3AL, Q-3BR, Q-3PI NH-3AL, NH-3BR SB-1AL, SB-1BR SBG
1 1/2 Q-4AL, Q-4BR, Q-4PI NH-4AL, NH-4BR SB-2AL, SB-2BR SBG
HOSE ID (in.) HOSE ENDS NOZZLE HOLDERS THREADED FEMALE ADAPTER GASKETS
T750AA
BLACK COVER
T750AG
GREEN COVER
10
