BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
38
KRHCA0109
Petroleum
APPLICATION
Oil feld vacuum tank service, for handling crude oil only.
NOTE: NOT RECOMMENDED FOR REFINED PETROLEUM
PRODUCTS.
COVER
Black, SBR, abrasion, ozone, limited oil resistance.
REINFORCEMENT
High tensile textile cords and
4
highly fexible steel helix wires.
TUBE
Black Nitrile – PVC blend, limited oil resistance, for oil feld use.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
100 feet: 2" through 6"
20 feet: 6" only
BRANDING
ALFAGOMMA – ITALY T601 10 BAR (150 PSI)
OIL RIGGER – OIL FIELD – S & D (in blue letters)
T601AA* - 150 PSI Oil Rigger/Oil Field Suction
Hose
COUPLING SUGGESTIONS
Combination nipples attached with bands.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
*
Note: All T601AA hose is stocked at our Houston, Texas and Santa Fe
Springs, California warehouses only.
T601AA200
2
51
2.40
61
91
150
10
T601AA300
3
76
3.46
88
169
150
15
T601AA400
4
102
4.57
116
232
150
20
T601AA600
6
152
6.61
168
444
150
30
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MAX. REC.
MIN. BEND
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
WP (PSI)
RADIUS (in.)
KRHCA 09
