BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
16
KRHCA0109
Water Discharge
T254AA - 150 PSI SBRWater Discharge Hose
APPLICATION
Water discharge hose for construction and irrigation.
COVER
Black abrasion and ozone-resistant SBR rubber.
REINFORCEMENT
High tensile textile cords.
TUBE
Black SBR
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
WORKING PRESSURE
Constant Pressure — 10 Bar (150 PSI)
STANDARD LENGTH
100 feet: 1
1
/
2
" through 8"
50 feet: 8"
COUPLING SUGGESTIONS
Quick-Acting, pin lug, short shank couplings or combination nipples attached with single bolt, double bolt, wire or band type clamps.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T254AA150
1 1/2
38
1.89
48
65
150
T254AA200
2
51
2.40
61
85
150
T254AA300
3
76
3.46
88
153
150
T254AA400
4
102
4.49
114
206
150
T254AA600
6
152
6.54
166
309
150
T254AA800
8
203
8.62
219
458
150
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MAX. REC.
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
WP (PSI)
