dixonvalve.comAG-Series Hydraulic Couplings
Body
Size
AG-Series Agricultural Interchange Ball Valve Coupler (Female Threads)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Threads
Material
Inch mm Inch mm
Bag Box
1/4"
2AGF2 1/4" - 18 NPTF steel
$24.43
2.11 53.5 1.06 27.0 7/8"
0.24 10 50
3/8"
3AGF3 3/8" - 18 NPTF steel
25.63
2.40 61.0 1.34 34.0 1-1/16" 0.51 10 50
1/2"
4AGF4 1/2" - 14 NPTF steel
29.20
2.62 66.5 1.49 37.8 1-1/4" 0.58 5 25
1/2"
4AGBF4 1/2" - 14 BSPP steel
33.97
2.62 66.5 1.49 37.8 1-1/4" 0.58 5 25
1/2"
4AGOF4 3/4" - 16 ORB steel
33.97
2.62 66.5 1.49 37.8 1-1/4" 0.64 5 25
1/2"
4AGOF5 7/8" - 14 ORB steel
35.76
2.62 66.5 1.49 37.8 1-1/4" 0.59 5 25
1/2"
4AGF6 3/4" - 14 NPTF steel
48.28
2.62 66.5 1.49 37.8 1-1/4" 0.71 5 25
3/4"
6AGF6 3/4" - 14 NPTF steel
65.56
3.35 85.0 1.89 48.0 1-1/2" 1.00 -
10
1"
8AGF8 1" - 11 1/2 NPTF steel
88.21
3.80 96.5 2.17 55.0 1-13/16" 1.89 -
10
Body
Size
AG-Series Agricultural Interchange Poppet Valve Coupler (Female Threads)
Part Detail
List
Price
Length Maximum OD Hex
Inch
Weight
Lb
Package Qty
Part Number
Threads
Material
Inch mm Inch mm
Bag Box
1/4"
2AGF2-PV 1/4" - 18 NPTF steel
$24.43
2.11 53.5 1.06 27.0 7/8"
0.24 10 50
3/8"
3AGF3-PV 3/8" - 18 NPTF steel
25.63
2.40 61.0 1.34 34.0 1-1/16" 0.51 10 50
1/2"
4AGF4-PV 1/2" - 14 NPTF steel
27.55
2.62 66.5 1.49 37.8 1-1/4" 0.58 5 25
1/2"
4AGBF4-PV 1/2" - 14 BSPP steel
32.05
2.62 66.5 1.49 37.8 1-1/4" 0.58 5 25
1/2"
4AGOF4-PV 3/4" - 16 ORB steel
32.05
2.62 66.5 1.49 37.8 1-1/4" 0.64 5 25
1/2"
4AGOF5-PV 7/8" - 14 ORB steel
33.73
2.62 66.5 1.49 37.8 1-1/4" 0.59 5 25
1/2"
4AGF6-PV 3/4" - 14 NPTF steel
45.55
2.62 66.5 1.49 37.8 1-1/4" 0.71 5 25
3/4"
6AGF6-PV 3/4" - 14 NPTF steel
65.56
3.35 85.0 1.89 48.0 1-1/2" 1.00 -
10
1"
8AGF8-PV 1" - 11 1/2 NPTF steel
88.21
3.80 96.5 2.17 55.0 1-13/16" 1.89 -
10
