BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
52
KRHCA0109
Material Handling
APPLICATION
Discharge of dry powders under low pressure, such as cement,
grains and animal feed transfer.
COVER
Black conductive SBR/NR blend — abrasion and ozone
resistant.
REINFORCEMENT
Spiralled high tensile textile cords.
TUBE
3/16" thick black static conducting natural rubber, compounded
to resist cutting by abrasive materials.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
100 feet
WORKING PRESSURE
Constant Pressure — 5 Bar (75 PSI)
BRANDING
ALFAGOMMA – ITALY T760 5 BAR (75 PSI)
BULK MATERIAL DELIVERY (in white letters)
T760AA - 75 PSI LightWeight Dry Powder
Delivery Hose
COUPLING SUGGESTIONS
Quick-Acting, pin lug, short shank couplings or combination nipples attached with single bolt, double bolt, wire or band type clamps.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T760AA400
4
102
4.53
115
160
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
H
Excessive bending during operation may cause premature wear.
KRHCA 09
