BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
44
KRHCA0109
Petroleum
APPLICATION
Oil discharge hose designed for use on trucks, docks or barges
where a soft wall hose is required.
COVER
Red CR — abrasion, ozone and hydrocarbon resistant.
REINFORCEMENT
Spiralled high tensile textile cords with embedded static wire.
TUBE
Black conductive NBR.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
100 feet
WORKING PRESSURE
Constant Pressure — 10 Bar (150 PSI)
BRANDING
ALFAGOMMA – ITALY T650 10 BAR (150 PSI) –
PETROLEUM DELIVERY (in yellow letters)
T650AH - 150 PSI Oil Discharge Hose
COUPLING SUGGESTIONS
Quick-Acting or combination nipples attached with bands.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T650AH150
1 1/2
38
1.89
48
62
T650AH200
2
51
2.40
61
81
T650AH300
3
76
3.46
88
142
T650AH400
4
102
4.49
114
192
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
