BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
42
KRHCA0109
Petroleum
T620AA - 300 PSI Black Fuel & Oil Suction &
Delivery Hose
APPLICATION
Fuel and oil suction and discharge for up to 50% aromatic
content. Designed for heavy duty applications.
COVER
Black conductive CR – abrasion, ozone and hydrocarbon
resistant.
REINFORCEMENT
High tensile textile cords, steel helix wires and static wire.
TUBE
Black conductive NBR.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
100 feet: 2" through 6"
20 feet: 6"
WORKING PRESSURE
Constant Pressure — 20 Bar (300 PSI)
BRANDING
ALFAGOMMA – ITALY T620 – 20 BAR (300 PSI)
PETROLEUM – S & D (in red letters)
Ω
COUPLING SUGGESTIONS
Quick-Acting, combination nipples attached with bands or internally expanded brass couplings with gasket seal attached with
ferrules.
H
Kuriyama offers a full line of Quick-Acting couplings, pin lug shank couplings and combination nipples. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T620AA200
2
51
2.48
63
112
8
T620AA300
3
76
3.54
90
178
12
T620AA400
4
102
4.57
116
241
16
T620AA600
6
152
6.69
170
516
24
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MIN. BEND
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
RADIUS (in.)
KRHCA 109
*T609AA - 240 PSI OS&D Hose is Being Discontinued.
