Page 18 - Alfagomma-Industrial-Rubber-Catalog-Revised-1-28-10

BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
18 KRHCA0109
Creamery Washdown
T350LL - PremiumWhite Cover Paper Mill
CreameryWash Down Hose - No Nozzle
APPLICATION
For general wash down service, using hot water or low
pressure saturated steam in processing plants and facilities and
in food and dairy plants.
COVER
White, heat, abrasion and ozone resistant EPDM rubber.
REINFORCEMENT
High tensile textile cords.
TUBE
White EPDM rubber.
TEMPERATURE RANGE
-40°F (-40°C) to 330°F (+165°C)
STANDARD LENGTH
200 feet — Eliminates bulky hookups.
WORKING PRESSURE
Constant Pressure — 15 Bar (225 PSI)
STEAM PRESSURE
Constant Pressure — 7 Bar (100 PSI)
BRANDING
Alfagomma – Italy – T350 7 BAR (100 PSI) STEAM
15 BAR (225 PSI) HOT WATER (embossed)
COUPLING SUGGESTIONS
Short shank, long shank couplings (NPT, GHT), barbed inserts attached with bands.
T350LL050 1/2 13 0.91 23 26
T350LL075 3/4 19 1.22 31 44
T350LL100 1 25 1.46 37 54
Nominal Specifcations
SERIES NO. NOMINAL ID NOMINAL OD APPROX. WT.
(in.) (mm) (in.) (mm) lbs./100 ft.
WHITE COVER
KRHCA 09
