BECAUSE WE CONTINUALLY EXAMINE WAYS TO IMPROVE OUR PRODUCTS, WE RESERVE THE RIGHT TO ALTER SPECIFICATIONS WITHOUT PRIOR NOTICE.
10
KRHCA0109
Compressed Air
APPLICATION
High quality air hose for heavy duty and mining applications.
COVER
Green, abrasion and ozone-resistant SBR rubber.
REINFORCEMENT
Spiralled, high tensile textile cords.
TUBE
Black SBR/NBR blend — oil mist resistant.
TEMPERATURE RANGE
-22°F (-30°C) to 176°F (+80°C)
STANDARD LENGTH
100 feet: 1/2" through 2"
50 feet: 1/2" through 2"
BRANDING
ALFAGOMMA – ITALY – T157 27 BAR (400 PSI) AIR (in blue
letters)
COUPLING SUGGESTIONS
Steel or malleable iron male insert NPT, female ground joint or washer type with spud, attached with 2 or 4 bolt interlocking clamps
or bands. Universal couplings may be used on sizes (
1
/
2
" – 2")
H
Kuriyama offers a full line of ground joint couplings and clamps and universal air hose couplings and clamps. Refer to current
Kuriyama-Couplings™ and Accessories Catalog for type and pricing.
T157AG - 400 PSI Textile Cord “Heavy Duty”
Air Drill Hose
T157AG050
1/2
13
0.91
23
28
400
T157AG075
3/4
19
1.14
29
38
400
T157AG100
1
25
1.38
35
48
400
T157AG125
1 1/4
32
1.73
44
73
400
T157AG150
1 1/2
38
1.97
50
86
400
T157AG200
2
51
2.56
65
114
400
Nominal Specifcations
SERIES NO.
NOMINAL ID
NOMINAL OD
APPROX. WT.
MAX. REC.
(in.)
(mm)
(in.)
(mm)
lbs./100 ft.
WP (PSI)
