Synthetic Mill Hose
Ideal for open end discharge applications. Not intended for fire fighting service.
Uncoupled
Coupled
Size Bowl Length Part #
1"
1"
1½"
1½"
1½"
2"
2"
2"
2½"
2½"
2½"
3"
3"
3"
4"
4"
4"
6"
6"
1-1/4"
1-1/4"
1-11/16"
1-11/16"
1-11/16"
2-1/4"
2-1/4"
2-1/4"
2-11/16"
2-11/16"
2-11/16"
3-3/8"
3-3/8"
3-3/8"
4-3/8"
4-3/8"
4-3/8"
6-3/8"
6-3/8"
50'
100'
25'
50'
100'
25'
50'
100'
25'
50'
100'
25'
50'
100'
25'
50'
100'
25'
50'
M10-50UC
M10-100UC
M15-25UC
M15-50UC
M15-100UC
M20-25UC
M20-50UC
M20-100UC
M25-25UC
M25-50UC
M25-100UC
M30-25UC
M30-50UC
M30-100UC
M40-25UC
M40-50UC
M40-100UC
M60-25UC
M60-50UC
Note: See page 169 for thread designation
Consult the factory for pricing and availability for any of the following features:
•75' lengths
•other threads and configurations
Coupled with female and male expansion ring couplings
•outer construction: single jacket, all synthetic
•tube construction: black, natural rubber liner
• ratings:
rated pressure: 250 PSI
working pressure: 112 PSI
uncoupled
Size Length Rocker Lug AluminumNPSH RAS Part #
Rocker Lug Aluminum
NST RAF Part #
Rocker Lug Aluminum
Customer Thread Part #
Rocker Lug Aluminum
MNPT x MNPT
1½"
1½"
2"
2"
2½"
2½"
2½"
50'
100'
50'
100'
25'
50'
100'
M15-50RAS
M15100RAS
M20-50RAS
M20100RAS
M25-25RAF
M25-50RAF
M25100RAF
M15-50RAF
M15100RAF
---
---
M25-25RAF
M25-50RAF
M25100RAF
---
---
---
---
M25-25RA___
M25-50RA___
M25100RA___
M15-50RAT
M15100RAT
M20-50RAT
M20100RAT
---
---
---
