PTFE Hose & Fittings
U
675
DPL413
877.963.4966 • dixonvalve.com
Nominal
Nominal Smooth Bore PTFE Hose
(
fittings not included
)
Nominal Fittings
Female SAE Swivel
Application:
Suitable for conveying chemicals, foods, pharmaceuticals, oils, gas, fuels and steam.
Features:
•
nominal standard smooth bore PTFE hose meets
SAE100R14
•
size range: dash-3 to dash-20
•
operating temperature:
-76°F
to
500°F
(-60°C to 260°C)
•
304 stainless braided
•
Extruded or heat shrink coverings are available upon
request.
•
boxed coils (bulk, per ft. lengths and full reels available
from Maryland and Texas call Dixon Specialty Products
at 888.226.4673)
Crimp Collars for all Nominal fittings are
included
1
double braided
Nominal
Size
Average
ID
Length in
Feet
Dash
Size
White, non-conductive tube
Black, conductive tube
Part #
Price/E
Part #
Price/E
3/16"
.125"
100 dash-3
WSB-03-100
$610.00
BSB-03-100
$790.00
1/4"
.187"
100 dash-4
WSB-04-100
640.00
BSB-04-100
705.00
5/16"
.250"
100 dash-5
WSB-05-100
635.00
BSB-05-100
695.00
3/8"
.312"
100 dash-6
WSB-06-100
825.00
BSB-06-100
905.00
3/8T"
.375"
100 dash-6T
WSB-06T-100
1065.00
BSB-06T-100
1175.00
1/2"
.405"
100 dash-8
WSB-08-100
950.00
BSB-08-100
1045.00
5/8"
.500"
100 dash-10
WSB-10-100
1250.00
BSB-10-100
1375.00
3/4"
.625"
100 dash-12
WSB-12-100
1405.00
BSB-12-100
1545.00
3/4T"
.750"
50
dash-12T
WSB-12T-50
1082.50
BSB-12T-50
1192.50
1"
.875"
50
dash-16
WSB-16-50
1186.00
BSB-16-50
1305.00
1T"
1.000"
50
dash-16T
WSB-16T-50
1640.00
BSB-16T-50
1807.50
1-1/4"
1.125"
50
dash-20Z
WSB-20Z-50
1
POR
BSB-20Z-50
1
POR
Female JIC Swivel
Hose
Size
Thread
Size
Carbon Steel
304 Stainless Steel
Brass
Box
Qty
Part # Price/E Part # Price/E Part # Price/E
dash 4
1/4"
FJC-04-04
$7.90
FJS-04-04
$21.15
FJB-04-04
$6.20
25
dash 5
5/16"
FJC-05-05
13.45
FJS-05-05
23.45
FJB-05-05
9.60
25
dash 6
3/8"
FJC-06-06
15.00
FJS-06-06
27.15
FJB-06-06
10.65
25
dash 8
1/2"
FJC-08-08
15.10
FJS-08-08
37.60
FJB-08-08
12.15
25
dash 10 5/8"
FJC-10-10
17.55
FJS-10-10
49.75
FJB-10-10
17.70
25
dash 12 3/4"
FJC-12-12
22.85
FJS-12-12
71.30
FJB-12-12
32.30
10
dash 16
1"
FJC-16-16
36.80
FJS-16-16
123.50
FJB-16-16
43.60
10
dash 20Z 1¼"
FJC-20Z-20
123.70
FJS-20Z-20
317.55
FJB-20Z-20
POR
5
Rigid Male Pipe
Hose
Size
Thread
Size
Carbon Steel
304 Stainless Steel
Brass
Box
Qty
Part # Price/E Part # Price/E Part # Price/E
dash 4
1/8"
MPC-04-02
$7.15
MPS-04-02
$13.40
MPB-04-02
$6.05
25
dash 4
1/4"
MPC-04-04
6.70
MPS-04-04
16.50
MPB-04-04
5.90
25
dash 5
1/4"
MPC-05-04
8.90
MPS-05-04
15.50
MPB-05-04
7.70
25
dash 6
1/4"
MPC-06-04
11.85
MPS-06-04
22.70
MPB-06-04
11.00
25
dash 6
3/8"
MPC-06-06
9.25
MPS-06-06
19.00
MPB-06-06
10.00
25
dash 8
3/8"
MPC-08-06
13.15
MPS-08-06
30.85
MPB-08-06
14.00
25
dash 8
1/2"
MPC-08-08
12.85
MPS-08-08
31.50
MPB-08-08
13.25
25
dash 10 1/2"
MPC-10-08
23.50
MPS-10-08
33.00
MPB-10-08
16.30
25
dash 12 3/4"
MPC-12-12
23.35
MPS-12-12
51.40
MPB-12-12
31.40
10
dash 16
1"
MPC-16-16
43.25
MPS-16-16
111.25
MPB-16-16
57.10
10
dash 20Z 1¼"
MPC-20Z-20
167.90
MPS-20Z-20
187.30
MPB-20Z-20
POR
5
Hose
Size
Thread
Size
Carbon Steel
Brass
Box
Qty
Part #
Price/E
Part #
Price/E
dash 6
3/8"
SAEC-06-06
17.65
SAEB-06-06
11.40
25
dash 12 3/4"
SAEC-12-12
24.75
SAEB-12-12
36.65
10
