Tank Truck Fittings
DPL413
R
877.963.4966 • dixonvalve.com 650
Dixon Diesel and Gasoline Nozzles
FuelMaster™ Diesel Nozzles
Big Mouth™ Diesel Nozzle
Farm and Consumer Nozzles
Fuel Nozzle Cross Reference
Features:
•Provides the high flow capacity required by many truck stops
and terminal operations.
• Micro-touch valve provides smooth operation and
exceptional flow control.
• These nozzles are not to be used with gravity flow tanks.
• super tough nylon hand guard and hold-open clip
• easy to change 'locknut style' spout assembly
• green scuff guard
• automatic shutoff
• Underwriter's Listed
•not designed for use with small 12 volt pumps, AC utility
pumps, farm pumps or consumer pumps
NPT
Inlet
Spout
Size
Wt
(lbs)
Approx. Flow
Rate at 20 PSI
(GPM)
Part # Price/E
1" 1-3/16" 3.5 30 DFN100HF $212.50
1" 1-3/16" 3.6 45 DFN100SF 295.50
Features:
• Micro-touch valve allows precise flow control
• Roto-matic latch pin provides positive auto shut-off
• This nozzle is not to be used with gravity flow tanks.
• pure PTFE packing eliminates stem leaks
•Super tough nylon hold-open clip and hand guard bend, but
won't break.
•Snap-on handle cover makes changing scuff guards easy.
• yellow scuff guard
• automatic shutoff
• Underwriter's Listed
•not designed for use with small 12 volt pumps, AC utility
pumps, farm pumps or consumer pumps
NPT
Inlet
Spout
Size
Wt
(lbs)
Approx. Flow
Rate at 20 PSI
(GPM)
Part # Price/E
1" 1-1/8" 3 20 DFN100 $164.30
Features:
• Automatic fuel nozzle designed for use with small 12 volt
and AC utility pumps as well as large farm and consumer
pumps.
•Heavy duty, stronger and more secure hook makes it easy
to hang the nozzle on the pump.
• These nozzles are not to be used with gravity flow tanks.
•black scuff guard on gasoline nozzle, green scuff guard on
diesel nozzle
• Underwriter's Listed
• automatic shutoff
1 gasoline nozzle
2 diesel nozzle
NPT
Inlet
Spout
Size
Wt
(lbs)
Approx. Flow
Rate at 20 PSI
(GPM)
Part # Price/E
¾" 13/16" 2½ 14 DN7UOBF 1 $120.80
¾" 15/16" 2½ 14 DN7LOBF 2 120.80
Dixon M. Carder OPW Emco Husky Catlow
DN7UOBF N7UOBF 1AF-40FS A2501F XSF-33704 NENLF
DN7LOBF N7LOBF 11APF-40FS A2501LF --- NELF
DFN100HF N4-Fuelmaster 7H A6000 V111-173310 MAX1
DFN100 N3-BigMouth N/A N/A 1HS.026810 MAC-1AH
diesel nozzle
DFN100HF
diesel nozzle
DFN100SF
gasoline nozzle
diesel nozzle
