Fire Fittings
O
541 DPL413 877.963.4966 • dixonvalve.com
SyntheticSingle Jacket Mill Hose
Application:
•Used in open end water discharge applications only. Not intended for fire fighting service.
Features:
• outer construction: single jacket, all polyester
• tube construction: black, natural rubber liner
• rated pressure: 250 PSI at ambient temperature (70°F)
• working pressure: 112 PSI at ambient temperature (70°F)
• Consult the factory for pricing and availability on 75' lengths and other threads and configurations.
Uncoupled
Coupled with female and male expansion ring couplings
Size Bowl Length Part # Price/E
1" 1-1/4" 50' M10-50UC $91.55
1" 1-1/4" 100' M10-100UC 183.00
1½" 1-11/16" 25' M15-25UC 50.45
1½" 1-11/16" 50' M15-50UC 101.00
1½" 1-11/16" 100' M15-100UC 202.00
2" 2-1/4" 25' M20-25UC 58.30
2" 2-1/4" 50' M20-50UC 117.00
2" 2-1/4" 100' M20-100UC 234.00
2½" 2-11/16" 25' M25-25UC 80.75
2½" 2-11/16" 50' M25-50UC 161.00
2½" 2-11/16" 100' M25-100UC 323.00
3" 3-3/8" 25' M30-25UC 96.60
3" 3-3/8" 50' M30-50UC 193.00
3" 3-3/8" 100' M30-100UC 387.00
4" 4-3/8" 25' M40-25UC 147.00
4" 4-3/8" 50' M40-50UC 294.00
4" 4-3/8" 100' M40-100UC 588.00
6" 6-3/8" 25' M60-25UC 259.00
6" 6-3/8" 50' M60-50UC 518.00
Size Length
Aluminum
Rocker Lug
NPSH RAS
Part #
Price
Aluminum
Rocker Lug
NST (NH) RAF
Part #
Price
Aluminum
Rocker Lug
MNPT x MNPT
Part #
Price
1½" 50' M15-50RAS $195.00 M15-50RAF $195.00 M15-50RAT $195.00
1½" 100' M15100RAS 284.00 M15100RAF 284.00 M15100RAT 284.00
2" 50' M20-50RAS 285.00 --- --- M20-50RAT 285.00
2" 100' M20100RAS 384.00 --- --- M20100RAT 384.00
2½" 25' M25-25RAS 217.00 M25-25RAF 217.00 --- ---
2½" 50' M25-50RAS 315.00 M25-50RAF 315.00 M25-50RAT 328.00
2½" 100' M25100RAS 474.00 M25100RAF 474.00 M25100RAT 490.00
