Fire Fittings
DPL413
O
877.963.4966 • dixonvalve.com 528
Features:
• 4 bolt hole pattern on flange
• 360° horizontal and 160° vertical travel
• other configurations available
Steel FirePro™ Monitor
Features:
• stainless steel discharge tip and ball bearings
•red epoxy finish standard
•150# ASA raised face 4" flange
•360° horizontal and 140° vertical travel
• seamless 2½" monitor - rated at 750 GPM
• Factory Mutual approved
Features:
• spinning teeth
• swivel nut
• operating pressure: 100 PSI (water only) at ambient
temperature (70°F)
• 200, 500, 800 GPM at 100 PSI
Primator 3000 Monitor
Master Stream Nozzles
Monitor Nozzle
Size Thread Weight Anodized Aluminum
Part # Price/E
2½" NST 10 lbs. PKF0186NST $2785.00
Features:
• factory set at 500 GPM
• a straight stream to fog 'quick throw' pattern change
• constant gallonage
• Factory Mutual approved
Size Thread Material Weight Part # Price/E
2½" NST brass 19 lbs. FP500B $2470.00
2½" NST aluminum --- FP500A 2055.00
Size Inlet Configuration Outlet Waterway Flow Weight Carbon Steel Part # Price/E
22" x 13" 4" flange 2½" male NST 2½" 750 GPM 50 lbs. FP475S $3400.00
Inlet
Configuration Outlet Waterway Flow Weight Aluminum
Part # Price/E
3" flange 2½" male NST 3" 800 GPM 28 lbs. PKF16646-300FL $4545.00
