Shank / Water Fittings
DPL413 877.963.4966 • dixonvalve.com 280
F
Quick Connect Fittings
(Bauer style)
Type B
Type B male with hose shank Type B female with hose shank with gasket
Type B male with male NPT Type B female with male NPT with gasket
Type B male with male NPT - extra long Standard Strainer Square Hole Type
Size
Inches
Galvanized Steel
Part # Price/E
2" MC3092 $43.50
3" MC3093 69.50
4" MC3094 124.90
6" MC3096 219.25
8" MC3098 422.00
10" MC30910 1 860.50
12" MC30912 1 1047.50
Size
Inches
Galvanized Steel
Part # Price/E
2" FC3102 $24.50
3" FC3103 33.00
4" FC3104 57.00
6" FC3106 97.50
8" FC3108 185.60
10" FC31010 376.75
12" FC31012 483.70
Size
Inches
Galvanized Steel
Part # Price/E
2" FCM3122 $40.50
3" FCM3123 51.50
4" FCM3124 83.25
6" FCM3126 142.50
8" FCM3128 293.00
Size
Inches
Galvanized Steel
Part # Price/E
2" MCM3112 $60.50
3" MCM3113 89.00
4" MCM3114 149.75
6" MCM3116 270.50
8" MCM3118 525.00
Size
Inches
Galvanized Steel
Part # Price/E
2" MCM3112XL $62.70
3" MCM3113XL 102.60
4" MCM3114XL 169.65
6" MCM3116XL 316.65
8" MCM3118XL 607.55
NPT
Size
Zinc Plated Steel
Part # Price/E
2" SHS25 $28.65
3" SHS35 45.75
4" SHS40 64.20
6" SHS60 185.70
8" SHS80 424.55
1 10" and 12" supplied with ACB304 lever assist bar
