Air Fittings
E
239 DPL413 877.963.4966 • dixonvalve.com
Series 1 Drip Leg Automatic Drain
Hex Nipples
Close Nipples
Application:
Used in compressed air systems to automatically expel liquids from piping systems. Installed at low points in piping and at end
of pipe network, where water is likely to accumulate.
Do not use pipe nipples as hose inserts.
Features:
• metal bowl
• drain is ported to 1/8" NPT
• inlet for metal bowl: 250 PSIG at ambient temperature (70°F)
Port Size Part # Price/E
1/2" 17-016-107 $281.75
• Stainless steel close nipples are available on page 628.
• Brass close nipples are available on page 315.
Size Carbon Steel
Part # Price/E
Opt Qty
1" x 1" CN100 $3.50 10
1-1/4" x 1-1/4" CN125 4.40 10
1-1/2" x 1-1/2" CN150 5.50 10
2" x 2" CN200 7.45 10
NPTF Thread Brass
Part # Price/E
Opt Qty
1/8" x 1/8" BCN12 $2.15 100
1/4" x 1/4" BCN25 2.78 100
3/8" x 3/8" BCN37 3.81 50
1/2" x 1/2" BCN50 5.64 25
3/4" x 3/4" BCN75 7.47 25
1" x 1" BCN100 17.77 10
• ref SAE 130137
