Air Fittings
E
233 DPL413 877.963.4966 • dixonvalve.com
Series 1 Micro-Fog Lubricators
SCFM ratings at 90 PSIG inlet pressure.
Application:
• Micro-fog lubricators, identified by a red adjusting screw, are used for applications containing one or more points of lubrication,
cylinders and multiple or single tools.
• Air flow through the lubricator lifts oil from the reservoir to the sight-feed dome. Oil is dropped into the fog generator and
atomized into a fine mist. Lightweight particles are delivered downstream for lubrication. Heavier particles fall back into the
reservoir.
• The micro-fog lubricator delivers 10% of the oil drops visible through the transparent sight-feed dome.
• Micro-fog lubricators cannot be filled under pressure.
Features:
• 7 oz. reservoir
• in-line or modular installation
• quick release bayonet bowl
• micro-fog design delivers
aerosol mist
• recommended lubricants: misting type oil rated
50 to 200 SSU (ISO Grade 7 to 46) at 100°F
• maximum operating conditions:
transparent bowl: 150 PSI and 125°F
metal bowl: 250 PSI and 175°F
Standard
transparent bowl
Features:
•1 qt. reservoir
• oil level sight gauge
• one turn threaded bowl attachment permits
easy maintenance
• inlet pressure: 250 PSI at ambient
temperature (70°F)
Jumbo
T
Jumbo General Purpose (Oil-Fog Only)
Features:
•2 gallon reservoir
• oil flow can be positively set
• reservoir is ASME
constructed
• inlet pressure: 250 PSI at
ambient temperature (70°F)
• oil level sight gauge
See pages 244-245 for lubricator accessories.
See page 136 for air tool lubricant.
metal bowl
metal bowl
Port
Size SCFM
Transparent Bowl Metal Bowl
Part # Price/E Part # Price/E
3/8" 114 L74M-3 $170.25 L74M-3MB $174.80
1/2" 154 L74M-4 170.25 L74M-4MB 174.80
3/4" 142 L74M-6 170.25 L74M-6MB 174.80
Port Size SCFM Metal Bowl with Sight Glass
Part # Price/E
¾" 160 L17-600A $346.05
1" 275 L17-800A 346.05
1¼" 275 L17-A00A 404.95
1½" 275 L17-B00A 404.95
Port Size SCFM Metal Bowl with Sight Glass
Part # Price/E
2" 1000 10-076-004 $5683.70
FRL's are designed for air service only, unless otherwise indicated.
