NOVEXBELTS
Novex belts are specially designed to run over small
sheave diameters at high speed ratios. Novex belts allow
use of narrow sheaves, small sheave diameters and short
centers for compact drives. The special ribbed top on
Novex belts provides traverse rigidity without increasing
bending stresses. This keeps Novex belts running cool
which means added life. Novex belt compounds have a
high degree of friction which allows the use of 60° belt
angle. This provides for better support of the tension
member.
NOTE All Novex belt size listings are in millimeters; ie, 5m = 5mm top
width; 280m = 280mm belt length. Top width and effective length (E.L.) are
listed in inches for size cross reference only.
3M also available. Contact Elgin for availability
Belt Sizes and Dimensions
Belt Belt Belt Belt Belt Belt
Belt E.L. Belt E.L. Belt E.L. Belt E.L. Belt E.L. Belt E.L.
No. (In.) No. (In.) No. (In.) No. (In.) No. (In.) No. (In.)
5M280 11.02 5M375 14.76 5M500 19.69 5M670 26.38 5M900 35.43 5M1180 46.46
5M290 11.42 5M387 15.24 5M515 20.28 5M690 27.17 5M925 36.42 5M1220 48.03
Nominal 5M300 11.81 5M400 15,75 5M530 20.87 5M710 27.95 5M950 37.40 5M1250 49.21
Top Width 5M307 12.09 5M412 16.22 5M545 21.46 5M730 28.74 5M975 38.39 5M1280 50.39
5M 5M315 12.40 5M425 16.73 5M560 22.05 5M750 29.53 5M1000 39.37 5M1320 51.97
3/16" 5M325 12.80 5M437 17.20 5M580 22.83 5M775 30.51 5M1030 40.55 5M1360 53.54
" 5M335 13.19 5M450 17.72 5M600 23.62 5M800 31.50 5M1060 41.73 5M1400 55.12
5M345 13.58 5M462 18.19 5M615 24.21 5M825 32.48 5N1090 42.91 5M1450 57.09
5M355 13.98 5M475 18.70 5M630 24.80 5M850 33.46 5M1120 44.09 5M1500 59.08
5M365 14.37 5M487 19,17 5M650 25.59 5M875 34.45 5M1150 45.28
7M500 19.69 7M670 26.38 7M900 35.43 7M1180 46.46 7M1600 62.99 7M2120 83.46
7M515 20.28 7M690 27.17 7M925 36.42 7M1220 48.03 7M1650 64.96 7M2180 85.83
Nominal
Top Width
7M
7M530
7M545
7M560
20.84
21.46
22.05
7M710
7M730
7M750
27.95
28.74
29.53
7M950
7M975
7M1000
37.40
38.39
39.37
7M1250
7M1280
7M1320
49.21
50.39
51.97
7M1700
7M1750
7M1800
66.93
68.90
70.87
7M2240
7M2300
88.19
90.55
5116"
7M580 22,83 7M775 30.51 7M1030 40.55 7M1360 53.54 7M1850 72.83 " 7M600
7M615
23.62
24.21
7M800
7M825
31.50
32.48
7M1060
7M1090
41.73
42.91
7M1400
7M1450
55.12
57.09
7M1900
7M1950
74.80
76.77
7M630 24.80 7M850 33.46 7M1120 44.09 7M1500 59.06 7M2000 78.74
7M650 25.59 7M875 34.45 7M1150 45.28 7M1550 61.02 7M2060 81.10
11M710 27.95 11 M950 37.40 11M1250 49.21 11M1700 66.93 11M2240 88.19
Nominal
Top Width
11M730
11M750
28.74
29.53
11M975
11M1000
38.39
39.37
11M1280
11 M1320
50.39
51.97
11M1750
11 M1800
68.90
70.87
11M2300 90.55
11M 11M775 30.51 11M1030 40.55 11M1360 53.54 11 M1850 72.83
7/16" 11M800 31.50 11M1060 41.73 11M1400 55.12 11 M1900 74.80
W 11M825
11M850
11M875
32.48
33.46
34.45
11 M1090
11 M1120
11 M1150
42.91
44.09
45.28
11M1450
11M1500
11 M1550
57.09
59,06
61,02
11M1950
11M2000
11M2060
76.77
78.74
81.10
11M900 35.43 11M1180 46.46 11M1600 62.99 11M2120 83.46
11 M925 36.42 11M1220 48.03 11M1650 64.96 11M2180 85.83
For sizes not shown contact Elgin for availability. Stock items subject to change without notice
