Thermoid® Select™ V-Belts Are A Perfect Fit!
Shown below is a quick reference outline about some
the belt products on the previous pages as well as a
number of our other popular belts. However, to see all
of our available Thermoid belt products, please visit
our Internet website or contact your area
HBD/Thermoid distributor for complete information.
WEDGE
Thermoid has gone
beyond the ordinary to
provide you with an
economical belt. The
deep V-design of the
Select™ Wedge belt
enables a smaller belt to
carry a bigger load. It
can operate at higher
speeds of up to 6,500
feet per minute. Belt width and groove spacing are
narrower and that reduces sheave face width 30% to
50% compared with classical belt drives. Decreased
sheave width means less shaft overhang, which in
turn places a lighter load on bearings and increases
bearing life. As belt drive systems are designed or
redesigned, consider Select Wedge belts – belts that
will do the job more economically and require less
space. Thermoid Select Wedge belts are resistant to
oil and heat and are static conductive.*
WEDGE COGGED
Select Wedge Cogged
belts are ideal for situa-
tions where weight or
sheave size is restricted.
In applications where
increased horsepower is
required, Select Wedge
Cogged belts – used
with sheaves as small as
2.2" in diameter, provide
higher horsepower in a given space when compared
to classical belts. This lets you utilize high speed
motors, which, according to the National Electrical
Manufacturers Association, can mean a 10% increase
in energy efficiency. The unique notched construction
distributes bending stress uniformly as well as provid-
ing superior heat dissipation. In most installations,
smaller diameter sheaves can be used, permitting
shorter center distances. Select Wedge Cogged belts
are raw edge construction and are cut to the precise
dimensions to fit the sheave groove. The result is
maximum wedging action and a reduced chance of
slippage. Tensile members are engineered to resist
fatigue and shock loads. Cord and rubber are specially
bonded to prevent separation. Reinforcement layers
on both sides of the tensile member help improve
cord stability. Select Wedge Cogged belts have
excellent resistance to heat, oil and ozone, and are
static conductive.
THERMOID® POWER TRANSMISSION
BELT PRODUCTS
SELECT™Classical (A, B, C, D)
SELECT™ Classical Cogged (AX, BX, CX)
SELECT™ Wedge (5V, 8V)
SELECT™ Wedge Cogged (3VX, 5VX)
Prime Mover Banded (B, C, D)
Maxipower™ Cogged Banded (3VX, 5VX)
Maxipower™ Banded (3V, 5V, 8V)
Double V (AA, BB, CC)
FHP (3L, 4L, 5L)
Metriflex™ (X PZ, XPA, XPB, SPC)
Multiribbed (H, J, K, L, M)
Novex (3M, 5M, 7M, 11 M)
Open End Prime Mover (A, B, C)
PowerPlus™ (3H, 4H, 5H)
PowerPlus™ Maxiband (5VK, 8VK)
Variable Speed
V-Link Belting: Accu-Link
Timing Trapezoidal (XL, L, H, XH, XXH)
Timing Dual Trapezoidal (XL, L, H)
HTD (3M, 5M, 8M, 14M) and STD (8M)
HTD Dual (8M, 14M) and STD Dual (5M)
HTD Heavy Duty (8M, 14M)
PU Endless (T5, T10, AT5, AT10)
PU Open Ended HTD (3M, 5M, 8M, 14M),
PU Open Ended STD (5M, 8M)
PU Open Ended (T5, T10, AT5, AT1O),
Trapezoidal (XL, L, H), Polyflat (F), NT Nubbed (N)
Rubber Open Ended HTD (5M, 8M), STD (8M)
* For an explanation of static conductivity and conditions,
