15
For Assistance:
800/835-0682
or E-Mail:
info@hbdthermoid.com
Product Series
Tuftex
®
, FlexKing
®
, Ultraflex
®
and related
products within the scope of these series.
A. Random Length(s) No Cuffed Ends
1.
Tuftex I.D. (Inside Diameter): ± .03
"
(1/32
"
)
FlexKing I.D. (Inside Diameter): Up to 8
"
-- -0
"
+ .06
"
Over 8
"
-- -0
"
+ .08
"
2.
O.A.L. (Overall Length): + 1/4
"
per foot length
- 1/8
"
per foot length
Note:
These product series when coiled, and stored
or shipped in this manner, will frequently “set” or tend
to remain in that position. They also have a tendency
to shrink 2 to 3% in overall length due to the nature of
relative light walled rubber, cotton or nylon. Duct/hose
can be installed to nominal length.
B. Cuffed (Soft End) Items
1.
Tuftex I.D. (Inside Diameter):
± .03
"
(1/32
"
)
FlexKing I.D. (Inside Diameter): Up to 8
"
-- -0
"
+ .06
"
Over 8
"
-- -0
"
+ .08
"
2.
O.A.L. (Overall Length):
±1/4”per foot length
3.
Cuff (Soft End) Length:
+ 1/4
"
- 1/8
"
Cyclone Series
A.
Random (Duct Excluding Cuffs)
1.
I.D.: + 1/4
"
- 1/8
"
2.
O.A.L.: + 1/2
"
per foot
- 1/8
"
per foot
B.
Cuff(s) Soft End(s)
1.
I.D.: + 1/4
"
- 0
"
2.
Cuff Lengths: +1
"
- 1/2
"
Product Series
Neoflex
®
, Silflex
®
and related
products within these series.
A.
Random Length (Plain Ends)
1.
I.D. (Inside Diameter): ± .03
"
(1/32
"
)
2.
O.A.L. (Overall Length): ± 1/4
"
per foot
B.
Cut to Length – Cuffed (Soft End Item)
1.
I.D. (Inside Diameter): ± .03
"
(1/32
"
)
2.
O.A.L. (Overall Length):
(a)
Under 18
"
O.A.L. ± 1/8
"
(b)
18
"
O.A.L. and longer ± 1/8
"
per foot
of length
3.
Soft Ends (Cuffs):
± 1/4
"
- 1/8
"
Standard Tolerances
The following tolerances apply to all Thermoid industrial ducting, unless otherwise stated or produced to a specific
customer’s blueprint.
