Silflex

®

Silflex ducting products are designed

to handle extreme high and low temperature air

handling applications ranging from -80°F to +550°F.

They are not recommended for applications involving

the movement of liquids or abrasive materials, or for

negative pressure applications. This ducting is extremely

flexible and can be easily installed around obstructions

and sharp bends. Typical applications include electronic

equipment cooling, paper processing equipment,

engine compartment air handling, and fume removal

from aluminum and glass manufacturing.

Silflex Type SSF –

Lightweight and extremely flexible, this ducting

minimizes waste since short sections can be joined together to form a

continuous length. It features a single ply of silicone coated fiberglass

fabric with an internally exposed helical wire reinforcement.

Silflex Type DSF –

This ducting features a double ply of silicone coated

fiberglass fabric with the helical wire reinforcement encased between two

plies of fabric. The liner allows for improved air flow and less air friction loss.

Plus, it also provides a higher pressure rating than the Silflex SSF.

Type SSF

Inside Diameter (inches)

2

3

4

5

6

Weight (lbs./ft.)

.19

.29

.38

.48

.58

Inside Bend Radius (inches)

.50

.75

1.0

1.25

1.50

Length Required for 180° Bend (inches)

8

12

16

20

24

Minimum Burst Pressure (psig)

102

88

69

57

41

Internal Working Pressure (psig)

26

22

17

14

10

Maximum Leakage (cfm/ft. at working pressure)

.010

.015

.020

.025

.030

Crush Resistance (lbs./ft.)

400

320

290

240

200

Axial Tensile Strength (lbs.)

375

535

660

870

900

Compressed Length (inches per foot)

3.5

2.5

2.1

2.0

Operating Temperature Range

-80°F to +550°F

Type DSF

Inside Diameter (inches)

2

3

4

5

6

Weight (lbs./ft.)

.20

.33

.44

.55

.66

Inside Bend Radius (inches)

.75

1.0

1.25

1.50

.175

Length Required for 180° Bend (inches)

10

14

19

24

28

Minimum Burst Pressure (psig)

165

142

125

76

68

Internal Working Pressure (psig)

42

35

31

19

17

Maximum Leakage (cfm/ft. at working pressure)

.016

.024

.032

.040

.048

Crush Resistance (lbs./ft.)

400

320

290

240

200

Axial Tensile Strength (lbs.)

525

680

860

900+

Compressed Length (inches per foot)

4.5

4

3.5

Operating Temperature Range

-80°F to +550°F

®

*

Silflex Type SSF

is normally available in 11 foot lengths, however this product can be ordered in a range of diameter sizes and lengths.

*

Silflex Type DSF

is normally available in 11 foot lengths, however this product can be ordered in a range of diameter sizes and lengths.

*

Contact Customer Service for complete details.
