Page 25 - CF Catalog 2-10

FEMALE SET
(with low-profile nut)
Steel/Ductile Iron
hose part list
size number each
1/2 RGJF-2 30.09
3/4 RGJF-3 36.44
1 RGJF-4 37.60
1-1/4 RGJF-5 65.97
1-1/2 RGJF-6 61.83
2 RGJF-8 74.48
2-1/2 RGJF-10 199.67
3 RGJF-12 208.00
4 RGJF-16 471.78
316 Stainless
1/2 RGJFSS-2 235.93
3/4 RGJFSS-3 244.77
1 RGJFSS-4 270.99
FEMALE SET
(with wing nut)
Steel/Ductile
hose part list
size number each
1/2 GJF-2 30.09
3/4 GJF-3 36.44
1 GJF-4 37.60
1-1/4 GJF-5 65.97
1-1/2 GJF-6 61.83
2 GJF-8 74.48
2-1/2 GJF-10 199.67
3 GJF-12 208.00
4 GJF-16 471.78
VITON SEAL HOSE STEM
(staked ferrule & low profile nut)
Steel
hose part list
size number each
1/2 ** **
3/4 ** **
1 ** **
VITON SEAL HOSE STEM
(staked ferrule & wing nut)
Steel
hose part list
size number each
1/2 ** **
3/4 ** **
1 ** **
INTERLOCKING MALE STEM
Steel
npt x part list
hose number each
1/4 X 1/4 IMS-1 6.24
1/4 X 3/8 IMS-1X38 6.94
3/8 X 1/4 IMS-38X1 7.19
3/8 X 3/8 IMS-38 5.39
3/8 X 1/2 IMS-38X2 7.22
1/4 X 1/2 IMS-1X2 7.22
1/2 X 3/8 IMS-2X38 9.65
1/2 X 1/2 IMS-2 6.01
1/2 X 3/4 IMS-2X3 13.06
3/4 X 1/2 IMS-3X2 15.17
3/4 X 3/4 IMS-3 9.24
3/4 X 1 IMS-3X4 20.61
1 X 3/4 IMS-4X3 20.25
1 X 1 IMS-4 13.57
Machined Ductile Iron
1-1/4 X 1-1/4 IMS-5 20.72
1-1/2 X 1-1/2 IMS-6 22.65
2 X 2 IMS-8 30.73
2-1/2 X 2-1/2 IMS-10 57.73
3 X 3 IMS-12 78.74
4 X 4 IMS-16 138.58
316 Stainless
1/2 X 1/2 IMSS-2 71.43
3/4 X 3/4 IMSS-3 77.92
1 X 1 IMSS-4 79.55
INTERLOCKING MALE STEM
(with staked ferrule)
Steel
hose part list
size number each
1/2 ** **
3/4 ** **
1 ** **
SWIVEL MALE STEM
(for use with steam)
Plated Steel
hose part list
size number each
3/4 IMS-3SW 32.98
SWIVEL MALE STEM
(with staked ferrule
for use with steam)
Plated Steel
hose part list
size number each
3/4 ** **
VITON SEAL HOSE STEM
Steel
hose part list
size number each
1/2 GJS-2 9.60
3/4 GJS-3 15.30
1 GJS-4 16.46
Machined Ductile Iron
1-1/4 GJS-5 25.38
1-1/2 GJS-6 25.38
2 GJS-8 31.82
2-1/2 GJS-10 54.25
3 GJS-12 85.11
4 GJS-16 157.95
316 Stainless
1/2 GJSS-2 84.55
3/4 GJSS-3 90.70
1 GJSS-4 115.30
VITON SEAL MALE END
(Viton seal x male npt)
Steel
npt part list
size number each
3/4 GJMS-3 47.61
1 GJMS-4 47.61
1-1/2 GJMS-6 77.80
2 GJMS-8 82.04
VITON SEAL FEMALE END
(Viton seal x female npt)
Steel
npt part list
size number each
3/4 GJFS-3 97.64
27
D
®
DISTRIBUTOR AUTHORIZATION
Safety is of paramount concern to every-
one. Due to the volatile nature of com-
pressed air and steam, and in
accordance with our ISO 9000 quality
system, we reserve the right to restrict
sales of our Ground Joint Viton® Seal
Couplings and U-Bolt Clamps to only
those distributors authorized by
Campbell Fittings.
Please contact our customer service
department for more information.
VITON SEAL
GROUND
JOINT
COUPLINGS
Viton should never be used with ammonia. . Please contact
our engineering department for information on all our gasketing materials.
** Contact Customer Service for part numbers, prices, and availability
