Page 37 - GOODYEAR RUBBER PRODUCTS 1-866-711-4673 Webstone Valves

- 34 -
T H I S S P AC E F OR D E S I GN E R / E NG I N E E R A P P ROV A L
Job/Customer ________________________________ Date _____________________ Contractor__________________________________________
Model Specified_______________________________ Qty ______________________ Approved By________________________________________
Designer/Engineer_____________________________ Date _____________________ Contractor’s PO #____________________________________
Submitted by _________________________________ Date_____________________ Other______________________________________________
T H I S S P AC E F OR D E S I GN E R / E NG I N E E R A P P ROV A L
Job/Customer ________________________________ Date _____________________ Contractor__________________________________________
Model Specified_______________________________ Qty ______________________ Approved By________________________________________
Designer/Engineer_____________________________ Date _____________________ Contractor’s PO #____________________________________
Submitted by _________________________________ Date_____________________ Other______________________________________________
Teflon® is a registered trademark of Dupont.
Teflon® is a registered trademark of Dupont.
First Digit 4 = IPS 5= Copper to Copper (Sweat)
Second Digit
Third Digit Product Group Number
Fourth Digit
Last Digit = Size
Options: SSW - 304 Stainless Steel Wing Style "T" Handle; T - Steel Wing Style "T" Handle; HV - High Velocity
0 = 1/4II
1 = 3/8II
2 = 1/2II
3 = 3/4II
4 = 1II
5 = 1 1/4II
6 = 1 1/2II
7 = 2II
8 = 2 1/2II
9 = 3II
10 = 4II
Webstone Company, Inc. warrants all of its products to be free from manufacturing
defects in material and/or workmanship for the life of the product provided they are
professionally installed and operated under normal conditions. Webstone will replace,
free of charge, any product or part thereof that proves defective in material and/or
workmanship under normal installation, use and service.
Webstone will also reimburse the installing contractor $50.00 to help cover the cost of
replacing any of our iso9002 valves found tobe defective inmaterial and/orworkmanship.
Contact us for complete details.
you can’t buy a better product at any price
COPPER BALL VALVE INSTALLATION INSTRUCTIONS:
When a ball valve requires connection to a copper tube, it is important that heat is applied only after the ball is
secured in a half open/half closed position. This will allow expansion from the heat applied to exit the ball cavity
without seat damage. Apply adequate flux to both the valve and the tube. Apply the torch flame to the copper tube and
allow the heat to transfer to the brass valve until the solder flows. Do not apply heat from torch directly on the brass
valve. Following this method f in tallation will prevent excessive heat on the Teflon® seats that could cause leaks,
damage to the valve and void all warranties.
page 34.
5 DIGIT PART NUMBERING SYSTEM
All orders placedwithWebstoneCompany, Inc. are nowprocessed by our automatedWeb
Track System. Upon receipt of your order, theWeb Track System processes it for shipment
the same day (if received by 1:00 PM EST). Immediately upon shipment of your order, web
track system information is transmitted to you, our customer, via fax. It serves as your
invoice and shipping confirmation. This confirmation invoice contains: Carrier Name, Pro
or Tracking Number, Quantities Shipped, Quantitie Back Ordered (if any) and your costs.
That means:
NO MORE long lead times for order shipment.
NO MORE calling to check on your order status.
NO MORE wondering if it will ship complete or partial.
The Web Track System is instant information with minimal paper and maximum efficiency.
It is part of a complete level of service that includes high fill rates 365 days a year.
We realize you have a choice in suppliers. We are committed to earning your business
everyday, and we give you the right reasons for choosing Webstone Company, Inc.
same day shipping and more
