Series: Push Pull
Interchange: ISO 16028
The Push Pull coupler is built
on the “A” Premier platform,
thus allowing breakaway
capabilities when the coupler is
unintentionally left coupled. It is
mounted in a clamp fixture that
is designed to be fixed-mounted
to the structure and when pulled
apart in line with the coupler,
the PPC Series coupler will
breakaway. It is recommended
to use the APM series nipple in
conjunction with this series for
mobile applications.
Applications
- Refuse compactor and
power units
- Trailer dump connections
- Snow plow application
- Agricultural implements
ISO 16028 Interchange
Flat Face Push Pull
Flat Face: Push Pull
BODY
SIZE
PORT
SIZE
THREAD
TYPE ORDER CODE PART DESCRIPTION
3/8 1/2 SAE PPC0608FO PUSH PULL FF 3/8 X 1/2 SAE
1/2 1/2 NPT PPC0808FP PUSH PULL FF 1/2 X 1/2 NPT
1/2 3/4 SAE PPC0812FO PUSH PULL FF 1/2 X 3/4 SAE
1/2 3/4 NPT PPC0812FP PUSH PULL FF 1/2 X 3/4 NPT
5/8 3/4 SAE PPC1012FO PUSH PULL FF 5/8 X 3/4 SAE
5/8 3/4 NPT PPC1012FP PUSH PULL FF 5/8 X 3/4 NPT
3/4 3/4 NPT PPC1212FP PUSH PULL FF 3/4 X 3/4 NPT
3/4 1 NPT PPC1216FP PUSH PULL FF 3/4 X 1 NPT
PPC SERIES CONSISTS OF COUPLER AND CLAMP ASSEMBLY COMPONENTS
