N-DURA - Type NP
Nylon Double Jacket Attack Hose
TYPE HOSE HOSE COLOR COUPLING THREAD COUPLING
I.D. X LENGTH TYPE SIZE TYPE MATERIAL
NP 15 = 1-1/2” 50 = 50’ Y = Yellow 15 = 1-1/2” N = NH Blank=
17 = 1-3/4” 100 = 100’ R = Red 20 = 2” I = IPT Aluminum
20 = 2” B = Blue 25 = 2-1/2”
25 = 2-1/2” O = Orange 30 = 3”
30 = 3” G = Green
T = Tan
Part Number Example: NP17X50R15N = NP N-Dura Hose, 1-3/4” ID by 50’ Length, Red, 1-1/2” Aluminum NH/NST
Threaded Coupling
How to Order
NP 17X50 R 15 N
SIZE SERVICE PROOF BURST WEIGHT FLAT HOSE BED BOWL
TEST TEST (For 50’ Coupled) WIDTH Volume (100’) SIZE
PSI (kPa) PSI (kPa) PSI (kPa) LBS (KG) IN FT 3 IN
1-1/2” 400 (2760) 800 (5515) 1200 (8275) 15 (6.8) 2.80 1.0 1-15/16
1-3/4” 400 (2760) 800 (5515) 1200 (8275) 16 (7.3) 3.20 1.0 2-3/16
2” 400 (2760) 800 (5515) 1200 (8275) 20 (9.1) 3.70 1.5 2-1/2
2-1/2” 400 (2760) 800 (5515) 1200 (8275) 26 (11.8) 4.50 2.0 3
3” 400 (2760) 800 (5515) 1200 (8275) 34 (15.4) 5.30 2.5 3-17/32
N-Dura® has an outstanding record of durability and value: 30 years of fireground
experience and millions of feet sold prove that it is one of America’s favorites.
Produced from high quality raw materials to exacting standards, this rubber lined,
nylon double jacketed hose has extinguished fires in every state, for the largest cities
and the smallest volunteer fire departments.
Properties and Construction
• Top quality, double jacket, rubber lined municipal fire hose made from 100% high
strength, low stretch, air-entangled nylon for enhanced abrasion and kink resistance
along with a lining of extruded EPDM rubber tube for long term adhesion.
• Outer jacket is manufactured with a tight weave with a high “pick” count to virtually
eliminate snagging and pulling while on the fireground.
• Reverse twill weave of the inner jacket provides a smooth waterway, delivering the
lowest friction loss in its class.
• The standard Dura-CoteTM treatment provides exceptional heat resistance, reduces
moisture absorption, and greatly increases abrasion and petrochemical resistance.
• Lining remains flexible to temperatures as low as -40°F (-40°C) and is highly
resistant to ozone and oxidation.
• Well suited for C.A.F.S. and foam solution application.
• National Fire Hose N-Dura® is manufactured in accordance with NFPA1961
standard, latest edition within our ISO-9001: 2000 certified quality assurance
system.
EPDM Rubber Liner
Nylon Inner Jacket
Nylon Outer Jacket
ATTACK
C.A.F.S.
Construction:
Nylon Double Jacket
EPDM Rubber Inner Liner
Temperature Range:
-40° to 150°F (-40° to 65°C)
Couplings Available:
Aluminum NH/NST or
IPT Threaded
Hose Colors:
