SUPREME -

Type FS

Polyester Double Jacket Attack Hose

Supreme is a durable, rugged, traditional double jacket fire hose and one of the

best values on the market today. Originally designed over 40 years ago, Supreme

has become the hose to which all others are compared. Manufactured to exacting

standards, our use of ring-spun polyester yarn with a flexible rubber liner and

calendered rubber backing, keeps this hose supple when empty and tough when

necessary.

Supreme hose sizes up to 3” were designed specifically for use as heavy duty attack

hose. It is manufactured to a service test pressure rating of 400 psi (2760 kPa) and

handles all problems of the fireground with ease.

Properties and Construction

• Premium quality, double jacket, EPDM (Ethylene Propylene Diene Monomer) rubber

lined fire hose made from 100% high tensile strength polyester yarn. The liner is

attached to the inner jacket using a rubber backing that is more flexible and has

higher heat resistance than other hoses using a Thermoplastic (TPU) adhesive.

• Optional Dura-Cote

TM

treatment greatly increases abrasion, heat, flame and

petrochemical resistance while virtually eliminating water pick-up. When treated,

Supreme is protected from mildew and no drying is required

• Supreme remains flexible to temperatures as low as -40°F (-40°C) and is highly

resistant to ozone and oxidation.

• Optional color-coded stripe of one contrasting color can be woven into the outer

jacket running the full length of the hose for identification purposes. See color chips

for hose and stripe options.

• Kink resistance exceeds that of lightweight jacketed hose.

• Suitable for use with C.A.F.S. and foam solutions.

• U.L. labeling is available on all sizes. FM approval is available on 1-½”

and 2-½” sizes.

• Ponn Supreme is manufactured in accordance with NFPA 1961 standard, latest

edition within our ISO-9001: 2000 certified quality assurance system.

ATTACK

C.A.F.S.

Construction:

Polyester Double Jacket

EPDM Rubber Inner Liner

with Rubber Backing

Temperature Range:

-40° to 150°F (-40° to 65°C)

Couplings Available:

Aluminum NH/NST or IPT

Threaded & Aluminum Storz

Approvals:

All sizes - UL Listed

1-1/2” & 2-1/2” Sizes - FM

Approved (see chart below

for specifics)

Stripe Colors:

Hose Colors:

LISTED

APPROVED

TYPE HOSE X

HOSE

COLOR

STRIPE** COUPLING THREAD COUPLING

OPTIONS

I.D.

LENGTH

COLOR

SIZE

TYPE

MATERIAL

FS

15 = 1-1/2” 50 = 50’

Y = Yellow

Y = Yellow 15 = 1-1/2” N = NH Blank=

UL=UL Labeled

17 = 1-3/4” 100 = 100’

R = Red

20 = 2”

I = IPT

Aluminum

FM=Factory Mutual

20 = 2”

B = Blue

25 = 2-1/2” S = Storz

25 = 2-1/2”

O = Orange

K = Black

30 = 3”

G = Green

T = Tan

Blank = (No Stripe)

C = White (Coated)

W = White (Uncoated)

Part Number Example:

FS17X50YR15N

= FS Supreme Hose, 1-3/4” ID by 50’ Length, Yellow and Red Stripe,

1-1/2” Aluminum NH/NST Coupling

How to Order

FS 17X50

Y

R 15

N

**Choose high contrast stripe color as compared to the selected hose color. Selection may not be available.

SIZE

SERVICE

PROOF

BURST

WEIGHT

FLAT

HOSE BED BOWL CERTIFICATION

TEST

(For 50’ Coupled) WIDTH Volume (100’) SIZE

AVAILABLE

PSI (kPa)

LBS (KG)

IN

FT 3

IN

1-1/2” 400 (2760) 800 (5515) 1200 (8275)

19 (8.6)

2.80

1.0

1-15/16

UL, FM

1-3/4” 400 (2760) 800 (5515) 1200 (8275)

20 (9.1)

3.20

1.0

2-3/16

UL

2”

400 (2760) 800 (5515) 1200 (8275)

22 (10)

3.60

1.5

2-7/16

UL

2-1/2” 400 (2760) 800 (5515) 1200 (8275)

32 (14.5)

4.50

2.0

3

UL, FM

3”

300 (2070) 600 (4140) 900 (6200)

39 (17.7)

5.40

2.5

3-9/16

UL

Polyester Inner Jacket

Polyester Outer Jacket

EPDM Rubber Liner

Rubber Backing
