Page 17 - GOODYEAR RUBBER PRODUCTS INC 1-866-711-4673 Snaptite Municipal Fire Hose Catalog

TPX - Type TPX
3-Ply Nitrile Rubber Attack/Supply Hose
Traditionally manufactured extruded hose can vary in thickness, becoming bulky
and heavy. Snap-tite TPX utilizes a 3-ply design where the ribbed cover and smooth
nitrile liner are extruded independently. The cover is inserted inside the tight-weave
reinforcement, vulcanized, then turned “inside-out”. The liner is then inserted and the
hose is vulcanized for a second time to form a bond of all three plies, guaranteeing a
consistent, compact hose wall.
This 3-ply design allows us to weave the polyester reinforcement tighter, making this
hose more resistant to puncture while also being easier to pack and store. TPX lays flat
and needs less hose bed space than typical extruded hose. When higher pressure
LDH is required for attack applications, please refer to our Snap-tite ATX hose found
on page M-20.
Properties and Construction
• TPX is a 3-ply nitrile rubber municipal fire hose with both the cover and liner made
independently along with high tensile strength polyester reinforcement for maximum
durability and flexibility.
• Smooth liner keeps friction loss to a minimum and is the best-in-kind, surpassed
only by Ponn Conquest.
• Nitrile rubber cover greatly increases abrasion resistance, provides long service life
and the tightly woven reinforcement resists puncture.
• Hose remains flexible to temperatures as low as -5°F (-20°C) and is resistant to
ozone, oxidation, and most chemicals or petroleum products.
• Suitable for attack, supply, and suction applications.
• Snap-tite TPX is manufactured in accordance with NFPA 1961 standard, latest
edition within our ISO-9001: 2000 certified quality assurance system.
TYPE HOSE HOSE COLOR COUPLING THREAD COUPLING
I.D. X LENGTH SIZE TYPE MATERIAL
Part Number Example: TPX40X50Y40S = TPX Hose, 4” ID by 50’ Length, Yellow, 4” Aluminum Storz Coupling
How to Order
TPX 40X50 Y 40 S
TPX 15 = 1-1/2” 50 = 50’ Y = Yellow 15 = 1-1/2” N = NH Blank=
17 = 1-3/4” 100 = 100’ R = Red 20 = 2” I = IPT Aluminum
20 = 2” K = Black 25 = 2-1/2” S = Storz
25 = 2-1/2” 30 = 3” BR= Brass
30 = 3” 35 = 3-1/2” Rocker Lug
40 = 4” 40 = 4”
50 = 5” 50 = 5” BP= Brass
60 = 6” 60 = 6” Pin Lug
80 = 8”
8” only available in
K=Black
SIZE SERVICE PROOF BURST WEIGHT FLAT HOSE BED BOWL
TEST TEST (For 50’ Coupled) WIDTH Volume (100’) SIZE
PSI (kPa) PSI (kPa) PSI (kPa) LBS (KG) IN FT 3 IN
1-1/2” 300 (2070) 600 (4140) 1000 (6900) 17 (8) 2.80 2.0 1-13/16
1-3/4” 300 (2070) 600 (4140) 1200 (8275) 19 (9) 3.25 2.5 2-1/16
2” 300 (2070) 600 (4140) 1200 (8275) 22 (10) 3.60 2.5 2-5/16
2-1/2” 300 (2070) 600 (4140) 1000 (6900) 30 (13.6) 4.30 3.5 2-13/16
3” 300 (2070) 600 (4140) 900 (6200) 38 (17.2) 5.10 4.5 3-5/16
4” 250 (1725) 500 (3450) 750 (5170) 45 (21) 6.60 5.0 4-5/16
5” 225 (1550) 450 (3100) 675 (4650) 55 (25) 8.20 7.5 5-5/16
6” 150 (1035) 300 (2070) 500 (3450) 70 (32) 9.90 12.5 6-5/16
8” 100 (690) 200 (1380) 400 (2760) 125 (57) 12.75 N/A N/A
Nitrile Rubber Liner
Polyester Inner Jacket
Nitrile Rubber
Outer Jacket
Construction:
3-Ply Nitrile Rubber Cover/Liner
Polyester Reinforcement
Temperature Range:
-5° to 200°F (-20° to 95°C)
Couplings Available:
Aluminum or Brass NH/NST
or IPT Threaded & Aluminum
Storz options
Hose Colors:
SOFT SUCTION
SUPPLY
ATTACK
M-17
