! WARNING !
FAILURE OR IMPROPER SELECTION OR IMPROPER USE OF THE PRODUCTS AND/OR SYSTEMS DESCRIBED HEREIN OR RELATED ITEMS CAN CAUSE DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE.
This document and other information from Snap-tite, Inc., its subsidiaries and authorized distributors, provides product and/or system options for further investigation by users having technical
expertise. It is important that you analyze all aspects of your application and review the information concerning the product or system in the current product catalog. Due to the variety of operation
conditions and applications for these products or systems, the user, through its own analysis and testing, is solely responsible for making the fnal selection of the products and systems and assuring
that all performance, safety and warning requirements of the application are met.
The products described herein, including without limitation, product features, specifcations, designs, availability and pricing, are subject to change by Snap-tite, Inc. and its subsidiaries
at any time without notice.
03-1153BE-1206
LIMITEDWARRANTY
Snap-tite warrants that it will replace defective products sold provided:
A. Customer notifes Snap-tite of any claims of defects in materials or workmanship within one year after receipt of shipment.
B. Return of goods is authorized by Snap-tite and then returned to the factory within 15 days after said authorization,
transportation charges pre-paid; and
C. Products or parts are found to be defective in materials and workmanship upon examination by Snap-tite.
Products shall not be considered as defective or nonconforming if they substantially fulfll performance requirements and are manufactured in
accordance with Snap-tite’s specifcations. This warranty will not extend to goods which have been subject to misuse, neglect, accident or
improper installation, misapplication under conditions not expressly made specifcally known to nor approved by Snap-tite in advance of shipment or
which have been repaired or altered outside our factory. Snap-tite’s liability shall be limited to replacement or repair of Snap-tite’s products.
www.Snap-titeHose.com
ISO-9001:2000 Certified
NFPA Pressure Rating Defnitions
Service Test Pressure:
Annual hydrostatic test to be conducted by purchaser on all in-service (used) hose to determine suitability for continued
use. The service test pressure is to be 10% greater than the “normal highest operating pressure” at which the hose is
expected to be used.
Unless otherwise instructed, this pressure is stenciled on all hose prior to shipment.
Proof/Acceptance Test Pressure:
The “one-time” test pressure, performed by the factory, on every new hose prior to shipment. The proof test pressure shall
not be less than 2 times the specifed service test pressure.
Burst Pressure:
The minimum burst test pressure shall not be less than 3 times the specifed service test pressure.
Operating/Working Pressure:
Maximum advised operating/working pressure that should not exceed 90% of the service test pressure (which is stenciled
on the hose) or the maximum operating pressure of the attached coupling.
