DIMENSIONS
H16000
H18000
H19000
H28000
H29000
H28005
H29005 CU6050LN CU6100LN
in / mm in / mm in / mm in / mm in / mm
A 19 483 19 483 20.125 512 11.5 296 11.5 296
B 20 508 20 508 14 356 11 280 11 280
C 15 381 15 381 10 254 2 49 2 49
D 10 254 16 407 16 407 6 150 10.5 267
E 12.5 318 18.5 470 18.5 470 11.25 286 15.625 397
F 5.75 146 5.75 146 5.75 146 5.5 140 5.5 140
Hand Crank
Air/Water/Oil/Grease
Series H - 3/8”, 1/2”, 3/4” I.D.
An economical reel designed for medium
duty applications requiring long lengths of
hose. Equally suited for plant or field use
such as lawn care, pest control, steam
cleaning and more. Shipped completely
assembled, ready to install.
H16000
SPECIFICATIONS
MODEL HOSE I.D. HOSE O.D. (F)NPTF
INLET LENGTH WEIGHT PRESSURE
in / mm in / mm in ft / m lbs / kg psi / bar
LOW PRESSURE AIR/WATER REELS : Maximum Temperature 150°F (65°C)
H16000 3/8 10 .688 18 3/8 300 91 32 15 500 35
H18000 1/2 13 .844 22 1/2 200 61 33 15 1000 69
H28005 1/2 13 .844 22 1/2 300 91 34 16 1000 69
H28000 1/2 13 .844 22 1/2 300 91 37 17 1000 69
H19000 3/4 19 1.118 31 3/4 100 30 33 15 1000 69
H29005 3/4 19 1.118 31 3/4 100 30 35 16 1000 69
H29000 3/4 19 1.118 31 3/4 150 46 41 19 1000 69
MEDIUM PRESSURE OIL REELS : Maximum Temperature 210°F (99°C)
H16000 M 3/8 10 .690 18 3/8 300 91 32 15 3000 207
H18000M 1/2 13 .815 21 1/2 200 61 35 16 3000 207
H19000M 3/4 19 1.118 31 3/4 80 24 38 18 3000 207
H29000 M 3/4 19 1.118 31 3/4 125 38 35 16 3000 207
HIGH PRESSURE GREASE REELS : Maximum Temperature 210°F (99°C)
H16000 H 3/8 10 .750 19 3/8 250 76 32 15 5000 345
Reels are supplied w/o hose; assemblies will be quoted upon request.
CAUTION: To prevent drum damage fully extend and pressurize hose and rewind on the reel.
Stainless models available. See page 16 and 17.
SPECIFICATIONS
MODEL HOSE I.D. (M)NPTF
OUTLET
(F)NPTF
INLET LENGTH WEIGHT PRESSURE
in / mm in in ft / m lbs / kg psi / bar
LOW PRESSURE AIR/WATER REELS : Maximum Temperature 150°F (65°C)
CU6050LN 3/8 10 3/8 3/8 50 15 10 4.5 250 18
CU6100LN 3/8 10 3/8 3/8 100 31 13 6 250 18
Reels are supplied w/o hose; assemblies will be quoted upon request.
Hand Crank Air/Water
Series CU - 3/8” I.D.
The Series CU is designed for lighter-duty applications that require longer lengths
of low pressure air/water hose. These reels are hand crank with a balanced brass
swivel and brass inlet. The product of lighter weight components and forward-thinking
design, the Series CU is an economical choice for storing and retrieving hose.
CU6050LN
CU6100LN
