21"
SAE 100R15
Compact SpiralTM
Bend Radius
Not only is it 1/2 the bend
radius, but it takes
1/3 less effort to bend.
Governmental agencies control
additional standards for particular
industries such as U.S.C.G. and
ABS. You must select a hose that
meets the legal requirements as
well as the functional requirements
of the application.
80 X
Tough
Cover (TC)
Standard
Rubber Cover
450 X
Super
Tough
(ST)
Cover
Results from the ISO 6945
metal-to-hose abrasion test show
that Tough Cover and Super Tough
cover hoses offer significantly
greater abrasion resistance than
standard rubber cover hose.
Levels of Abrasion Resistance
Metal-to-Hose Abrasion Resistance
Hose Hint
A hose assembly should
be routed so that the
hose is not stretched,
compressed, or kinked
to assure maximum
service life and safety.
