Page 25 - 22006_PacEcho_Inside_Spreads3

A=SATISFACTORY
B=BE EXPECTED TO CHANGE
C=UNSATISFACTORY
Chemical Resistance Rating at 68°F
Acetone A
Ammonia A
Ammonia Solution A
Ammonium Carbonate A
Amyl Acetate B
Amyl Alcohol A
Animal Oil B
ASTM No. 1-3 Oil C
Benzene C
Butane C
Butyl Alcohol B
Butyl Acetate B
Butylene Calcium Hydroxide A
Carbonic Acid Gas B
Carbonic Dioxide A
Cement A
Citric Acid A
Coal Tar C
Cottonseed Oil C
Creasote C
Crude Oil C
Cyclo Hexane B
Diesel Oil C
Dilute Nitric Acid C
Dilute-Sulphuric Acid 50% B
Ethyl Alcohol A
Ethylene Glycol A
Farma Line A
Fish Oil C
Formic Acid A
Fuel Oil C
Gas C
Glycerol A
Glycol A
Grain A
Chemical Resistance Rating at 68°F
Hexanol B
Hydrochloric Acid A
Hydrogen Sulfide C
Iron Ore B
Iso-Octane C
Iso-Proply Alcohol A
Latex C
Magnesium Chloride A
Magnetite Sand A
Methane C
Methanol A
Methyl Acetate B
Naptha C
Nierus Acid B
Octyl Alcohol A
Oxygene A
Phosphoric Acid A
Phosphoric Slurry B
Potassium Hydroxide A
Potassium Phosphate B
Propane C
Propyl Acetate B
Propylene C
Silicic Acid C
Sodium Acetate A
Soybean Oil C
Sodium Hydroxide C
Steam A
Suffurous Acid Gas A
Toluene C
Vegetable Oil C
Wood Chip B
Xylene C
Xylole C
Zinc Acetate A
Zinc Sulfate A
PROPERTIES OF SPIRALITE® 2000
O=EXCELLENT RESISTANCE
!=GOOD RESISTANCE
X=POOR RESISTANCE
2000 Vinyl Conventional
Condition EPDM Suction Rubber Suction
Weather Resistance O O X
Aging Resistance O ! O
Property Under Low Temperature ! X O
Property Under High Temperature ! ! O
Property of Helix Cracking O X !
Electro Conductivity O X !
Bending Habit ! X O
Oil Resistance X ! X
Acid Resistance ! ! X
Alkali Resistance O ! O
Agricultural Chemical Resistance O ! X
The radius to which a hose can be bent
in service without damage or lowering
its life which is measured to the inside
of the curvature.
BEND RADIUS DEFINITION
