OETIKER
Clamps and Rings
Product Chart
www.oetiker.com Rights to make technical changes in the interests of further development reserved 08901456
®
Safe and Secure
No matter where or what needs to
be connected, there is hardly any
connection problem which cannot
be solved. OETIKER Clamps and
Rings can connect practically
anything from hoses, pipes, cables,
ropes and other objects, in all
different materials and under the
toughest conditions, securely and
permanently – disconnection only
as required.
OETIKER solutions for connections
in a wide variety of applications
and industries prove themselves
in use day in and day out:
• Agriculture
• Respiratory Protection
• Building
• Mining
• Chemicals and Petrochemicals
• Electrical and Electronic Industries
• Automotive Supply Industry
• Food and Beverage Industry
• Aerospace Industry
• Medical Industry
• Automotive Industry
• Military
• Rail Industry
• Ship Building
• Welding
• Repair and Maintenance
Application and Selection
Clamp Sealing performance is
dependent on:
• Material, hardness, and shape
of the parts to be connected
• Geometric formation between
the inside diameter of the
hose and the part/surface to
be connected
• Pressure loads, temperature
and environmental influences,
type of medium, mechanical
stresses (i.e. vibration)
• Correct selection and
installation of the clamp
Send your sample parts and all
relevant information for your
specific application to OETIKER,
and we will send you our
recommendation for product
type, diameter, and method of
installation to suit your needs.
150
168
192
194
167
Multi Crimp Rings
Ø 5.0 - 120.0 mm
Page 11
Stepless ® Low Profile Clamps
Ø 10.5 - 120.0 mm
Page 9
Stepless® Low Profile
Clamps 192
Ø 28.0 - 120.5 mm
Page 10
Stepless® Ear Clamps
Ø 6.5 - 120.5 mm
Page 8
Clamps ER
Ø 4.8 - approx. 25 mm
Page 12
105&155
1-Ear Clamps
with Mechanical Interlock
Ø 10.5 - 116 mm
Page 13
