Marine Hose Catalogue
SERIES
104OB
ODOR BLOCK SANITATION
The best rubber sanitation hose
available to prevent odor permeation
in marine waste systems. New copolymer
tube designed to exceed industry requirements
and be highly flexible and easy to connect.
Suction (full vacuum) and discharge applications.
Operating temperature: -40º to 200ºF (-40º to 93ºC)
Max Working Pressure: 75psi with worm gear clamps
150 psi with industrial couplings & clamps or bands.
SIZE: 1”, 1
1
/
2
”
SERIES
104
COST EFFECTIVE PREMIUM
SANITATION HOSE
The industry’s premium sanitation
hose. Designed and compounded
to provide maximum resistance to odor
permeation. Helical wire construction provides
flexibility and collapse resistance for applications requiring a
tight bend radius. Best choice for connection between head
and holding tank, and holding tank to pump out.
SIZE: 1”, 1
1
/
4
”, 1
1
/
2
”, 1
7
/
8
”, 2”, 2
1
/
4
”
SERIES
140
CORRUGATED PVC
SANITATION HOSE
Flexible PVC hose designed
primarily as a discharge hose.
Applications include: potable
water fill, drain lines, holding
tank pump-out and bilge discharge.
FDA approved compound.
NOT DESIGNED FOR BELOW
WATERLINE APPLICATIONS.
SIZE:
5
/
8
”, 1”, 1
1
/
2
”, 2”
SERIES
144
ODOR PROTECTOR
SANITATION
A newly formulated premium PVC resin
specifically developed to prevent odor
permeation commonly found in marine
waste systems. This newly designed resin
protects against odor permeation. Highly flexible and compatible
with all sanitation systems. Suction and vacuum applications.
Operating temperature: 5º to 158ºF (-12º to 70ºC)
Max Working Pressure: 50psi with worm gear clamps.
SIZE: 1”, 1
1
/
2
”
SERIES
146
SANITATION
HOSE CUFFS
(RIGHT HAND THREAD)
FDA materials, deep thread
design for “hold fast” installation.
Cuff taper allows for easy
attachments to all major valves.
SIZE: 1
1
/
2
”
SERIES
148
H. D. SMOOTH PVC
SANITATION HOSE
Heavy duty PVC hose designed
for sanitation systems. Smooth
interior and exterior provide
excellent clamping surface. Helical
rod design provides flexibility and collapse
resistance. Produced with FDA approved materials.
SIZE:
5
/
8
”,
3
/
4
”, 1”, 1
1
/
8
”, 1
1
/
4
”, 1
1
/
2
”, 2”
Sanitation
SYSTEMS
