286
TECHNICAL DATA
Fluid:
Compressed Air
Operating Pressure:
Transparent bowl: 150 psig
Metal bowl: 250 psig
Automatic drain: 150 psig
Operating temperature*:
Transparent bowl: -30° to 150°F
Metal bowl: -30° to 150°F
*Air supply must be dry enough to avoid ice formation at
temperatures below 35°F.
FILTERS
MATERIALS
F72G
Body: zinc
Transparent Bowl: polycarbonate
Element: sintered polypropylene
Elastomers: neoprene and nitrile
F73G & F74G
Body: aluminum
Metal bowl: aluminum
Metal bowl liquid level indicator lens:
transparent nylon
Element: sintered polypropylene
• Quick release bayonet bowl.
• Optional service life indicator turns from green to red when the filter element needs to be replaced.
Part # Size Description
F72G 1/4" General purpose filter ----
F73G 3/8" General purpose filter ----
F74G 1/2" General purpose filter ----
GENERAL P URPOSE FILTERS PNEUMATICS
A
CCESSORIES
Manual Drain Available
