13
B
RASS
Hose Barb Fittings
•Temperature and Working Pressure Ranges
From -400F to + 160 0F at 150 PSI maximum.
• Tolerance
+/- .02 on all dimensions. Dimension Data can change
without notice. Please call us when dimensions are criti-
cal.
•Material
CA360 Brass for Barstock fittings.
CA377 Brass for Forged fittings.
Note: These fittings are intended for use with hose clamp,
similar type clamp or a crimped ferrule.
• Assembly Instructions
1- Cut hose cleanly and squarely to length.
2- Slide clamp on hose.
3- Lubricate hose. Push hose on fitting until hose
bottoms against stop ring or hex.
4- Position hose clamp as shown below and secure
with a screwdriver or wrench. Maintain “A”
dimension noted below for proper clamp position-
ing.
See page 255-269 for hose clamps
See page 248-249 for plastic hose barb fittings
See page 26 for stainless steel hose barbs
Actual Profile of Hose Barbs
.165 .227 .29 .354 .415 .53 .645 .79 1.02
1/8"
3/16" 1/4" 5/16"
3/8"
1/2"
5/8" 3/4" 1"
Hose Barb HOSE BARB BRASS FITTINGS
Stainless Steel hose barbs for beverage service available -
See beverage fitting section, pg. 301
